▶ EngineEngine Manufacturer FPT Doosan Engine Model F5D Not Published Engine Type 4-cylinder diesel Turbocharged, four stroke intercooled, direct injection diesel No. of Cylinders 4 4 Displacement 207 in³ 208 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 106 hp 105 hp PTO Power 91 hp 95.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Direct injection Alternator 120 A 85 A ▶ HydraulicsPump Type Gear pumps Not Published Implement Flow T5.105: 16.1 gpm (21.1 gpm optional); T5.105 Electro Command: 21.1 gpm (16.1 gpm optional) 15.6 gpm Steering Flow T5.105: 10.0 gpm (11.4 gpm optional); T5.105 Electro Command: 11.4 gpm (10.0 gpm optional) 7.1 gpm Total Hydraulic Flow T5.105: 26.1 gpm (16.1 + 10.0, computed); T5.105 Electro Command: 32.5 gpm (21.1 + 11.4, computed) Not Published Overall Hydraulic Pump Flow T5.105: 26.1 gpm (16.1 + 10.0, computed); T5.105 Electro Command: 32.5 gpm (21.1 + 11.4, computed) Not Published Hydraulic System Type Open center Open center, full-live electro-hydraulic with position and draft controls Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (3 optional) 3 (mFORCE 105P); 2 (mFORCE 105S) No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 37 gal 33.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic clutch Electro-hydraulic PTO Rear 540/1000 540 @ 2220 rpm, 750 @ 2208 rpm, 1000 @ 2227 rpm (mFORCE 105P); 540 @ 2220 rpm, 1000 @ 2227 rpm (mFORCE 105S) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II ball joints with telescopic lower links and adjustable outside stabilizers Hitch Lift Capacity Not Published 6,860 lb (measuring point not stated by Mahindra) Hitch Lift Capacity (at 24”) T5.105: 6,393 lb (10,452 lb with 2 optional rams); T5.105 Electro Command: 6,393 lb (8,809 lb with 1 optional ram, 10,452 lb with 2) Not Published Lift Control Type Electronic draft control Position and draft control ▶ Transmission & DrivetrainTransmission Type T5.105: 12x12 power shuttle (standard), 20x20 power shuttle with creeper or 24x24 Dual Command power shuttle (optional); T5.105 Electro Command: 16x16 power shuttle (standard), 32x32 power shuttle with creeper (optional) Power shuttle, power shift with synchromesh (mFORCE 105P); power shuttle with synchromesh (mFORCE 105S) No. of Speeds T5.105: 12F/12R (20F/20R or 24F/24R optional); T5.105 Electro Command: 16F/16R (32F/32R optional) 24F / 24R + 8 creepers (mFORCE 105P); 12F / 12R (mFORCE 105S) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Wet multi-plate Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock; limited slip front Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power with tiltable column Brakes Hydraulic wet disc Wet disc Seat Suspension & Adjustability Numerous seat options including a premium low-frequency heated air-suspension seat; full-size instructor seat available Pneumatic suspension seat Front Axle Type Heavy-duty 4WD front axle (standard) Not Published Front Axle Rating 4,500 lb (in-action capacity at 4 mph) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch T5.105: 163.8 in; T5.105 Electro Command: 165.0 in 162 in Overall Width 82.6 in 84.3 in Wheelbase 92.5 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 11.98 ft Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model T5.105: 105.4 in; T5.105 Electro Command: 105.6 in (non-suspended cab), 107.2 in (suspended cab) 107 in ▶ WeightTractor Weight (Base) T5.105: 9,370 lb; T5.105 Electro Command: 9,700 lb 8,666 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published 13.6R 24 R1 Agricultural - Rear Not Published 18.4R 34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or European-style Not Published Loader Model 825TL; 835TL (each NSL or MSL) 105L Loader Lift Height 825TL: 138 in; 835TL: 146 in 105L: 141.7 in Loader Lift Capacity (Full Height) 825TL NSL: 2,843 lb; 825TL MSL: 2,954 lb; 835TL NSL: 3,483 lb; 835TL MSL: 3,681 lb 105L: 4,129 lb Loader Breakout Force 825TL NSL: 2,976 lb; 825TL MSL: 3,284 lb; 835TL NSL: 3,725 lb; 835TL MSL: 4,100 lb 105L: 6,025 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year limited powertrain warranty
