▶ EngineEngine Manufacturer FPT KIOTI (Daedong) Engine Model F5D 4J243TA-TP5B Engine Type 4-cylinder diesel In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4J243TA-TP5B) No. of Cylinders 4 4 Displacement 207 in³ 233.9 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 114 hp 115.3 hp PTO Power 98 hp 83.9 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dry element with evacuator valve Fuel System Not Published Common Rail Direct Injection (CRDI) Alternator 120 A Not Published ▶ HydraulicsPump Type Gear pumps Gear Implement Flow T5.115: 16.1 gpm (21.1 gpm optional); T5.115 Electro Command: 21.1 gpm (16.1 gpm optional) 19.8 gpm Steering Flow T5.115: 10.0 gpm (11.4 gpm optional); T5.115 Electro Command: 11.4 gpm (10.0 gpm optional) 12.2 gpm Total Hydraulic Flow T5.115: 26.1 gpm (16.1 + 10.0, computed); T5.115 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 32 gpm Overall Hydraulic Pump Flow T5.115: 26.1 gpm (16.1 + 10.0, computed); T5.115 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 32 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (3 optional) 3 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 37 gal 47.6 gal Coolant Capacity Not Published 4.7 gal Crankcase Capacity Not Published 3.9 gal Transmission / Hydraulic System Capacity Not Published 20.34 gal Front Axle Fluid Capacity Not Published 2.6 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic clutch Independent PTO Rear 540/1000 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 8,079 lb Hitch Lift Capacity (at 24”) T5.115: 6,393 lb (10,452 lb with 2 optional rams); T5.115 Electro Command: 6,393 lb (8,809 lb with 1 optional ram, 10,452 lb with 2) 8,002 lb Lift Control Type Electronic draft control Electronic control ▶ Transmission & DrivetrainTransmission Type T5.115: 12x12 power shuttle (standard), 20x20 power shuttle with creeper or 24x24 Dual Command power shuttle (optional); T5.115 Electro Command: 16x16 power shuttle (standard), 32x32 power shuttle with creeper (optional) Power Shuttle w/ Hi-Lo Shift No. of Speeds T5.115: 12F/12R (20F/20R or 24F/24R optional); T5.115 Electro Command: 16F/16R (32F/32R optional) 24 forward / 24 reverse Max Travel Speed (Forward) Not Published 23.83 mph Max Travel Speed (Reverse) Not Published 23.67 mph Clutch Not Published Wet Multi Disc Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock; limited slip front Mechanical rear differential lock (standard); front limited-slip differential ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Hydraulic wet disc Wet Multi Disc Seat Suspension & Adjustability Numerous seat options including a premium low-frequency heated air-suspension seat; full-size instructor seat available Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Front Axle Type Heavy-duty 4WD front axle (standard) 4WD with outboard planetary final drives and limited-slip differential Front Axle Rating 4,500 lb (in-action capacity at 4 mph) Not Published Drawbar Capacity Not Published Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch T5.115: 163.8 in; T5.115 Electro Command: 165.0 in 170.8 in Overall Width 82.6 in 88.6 in Wheelbase 92.5 in 94.9 in Ground Clearance Not Published 18.9 in Min. Turn Radius without Brakes Not Published 12.7 ft (with brake applied) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model T5.115: 105.4 in; T5.115 Electro Command: 105.6 in (non-suspended cab), 107.2 in (suspended cab) 111.9 in ▶ WeightTractor Weight (Base) T5.115: 9,370 lb; T5.115 Electro Command: 9,700 lb 10,230 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) R1 Agricultural - Front Not Published 13.6-24 R1 Agricultural - Rear Not Published 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or European-style KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Loader Model 825TL; 835TL (each NSL or MSL) KL1155 Loader Lift Height 825TL: 138 in; 835TL: 146 in KL1155: 150.6 in (to pivot pin) Loader Lift Capacity (Full Height) 825TL NSL: 2,843 lb; 825TL MSL: 2,954 lb; 835TL NSL: 3,483 lb; 835TL MSL: 3,681 lb KL1155: 4,216 lb (at pivot pins) Loader Breakout Force 825TL NSL: 2,976 lb; 825TL MSL: 3,284 lb; 835TL NSL: 3,725 lb; 835TL MSL: 4,100 lb KL1155: 8,554 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage Not Published Tractors (Non-Commercial): 24 months parts & labor, unlimited hours, 0% deductible; powertrain (engine and driveline): 48 months unlimited hours on HX Series
