▶ EngineEngine Manufacturer FPT AGCO Power Engine Model F5D Not Published Engine Type 4-cylinder diesel 4-cylinder, turbocharged intercooled diesel No. of Cylinders 4 4 Displacement 207 in³ 268.5 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 114 hp 115 hp PTO Power 98 hp 90 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Not Published High-pressure common-rail direct fuel injection Alternator 120 A Platform: 80 A; Cab: 120 A ▶ HydraulicsPump Type Gear pumps Engine-driven gear pump Implement Flow T5.115: 16.1 gpm (21.1 gpm optional); T5.115 Electro Command: 21.1 gpm (16.1 gpm optional) 15.3 gpm Steering Flow T5.115: 10.0 gpm (11.4 gpm optional); T5.115 Electro Command: 11.4 gpm (10.0 gpm optional) 8.5 gpm Total Hydraulic Flow T5.115: 26.1 gpm (16.1 + 10.0, computed); T5.115 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 23.8 gpm (15.3 + 8.5, computed) Overall Hydraulic Pump Flow T5.115: 26.1 gpm (16.1 + 10.0, computed); T5.115 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 23.8 gpm (15.3 + 8.5, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 26 gpm No. of Standard Remote Valves 2 (3 optional) 2 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 37 gal 52.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic clutch Independent, electrohydraulic engagement PTO Rear 540/1000 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 9,480 lb Hitch Lift Capacity (at 24”) T5.115: 6,393 lb (10,452 lb with 2 optional rams); T5.115 Electro Command: 6,393 lb (8,809 lb with 1 optional ram, 10,452 lb with 2) 7,500 lb Lift Control Type Electronic draft control Not Published ▶ Transmission & DrivetrainTransmission Type T5.115: 12x12 power shuttle (standard), 20x20 power shuttle with creeper or 24x24 Dual Command power shuttle (optional); T5.115 Electro Command: 16x16 power shuttle (standard), 32x32 power shuttle with creeper (optional) 12 x 12: 2-range power shuttle with electrohydraulic shuttle lever; Dyna-4: semi-powershift No. of Speeds T5.115: 12F/12R (20F/20R or 24F/24R optional); T5.115 Electro Command: 16F/16R (32F/32R optional) 12 x 12: 12F/12R; Dyna-4: 16F/16R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Multidisk wet clutch with electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock; limited slip front Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Numerous seat options including a premium low-frequency heated air-suspension seat; full-size instructor seat available ROPS: mechanical spring suspension with armrests; Cab: air-ride swivel seat Front Axle Type Heavy-duty 4WD front axle (standard) Heavy-duty 4WD front axle Front Axle Rating 4,500 lb (in-action capacity at 4 mph) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch T5.115: 163.8 in; T5.115 Electro Command: 165.0 in 165.6 in Overall Width 82.6 in Dyna-4 cab: 74.9 in; 12 x 12 cab: 79.8 in Wheelbase 92.5 in 95.7 in Ground Clearance Not Published 20.3 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model T5.115: 105.4 in; T5.115 Electro Command: 105.6 in (non-suspended cab), 107.2 in (suspended cab) 105.7 in ▶ WeightTractor Weight (Base) T5.115: 9,370 lb; T5.115 Electro Command: 9,700 lb ROPS: 9,195 lb; Cab: 10,011 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or European-style Not Published Loader Model 825TL; 835TL (each NSL or MSL) Not Published Loader Lift Height 825TL: 138 in; 835TL: 146 in Not Published Loader Lift Capacity (Full Height) 825TL NSL: 2,843 lb; 825TL MSL: 2,954 lb; 835TL NSL: 3,483 lb; 835TL MSL: 3,681 lb Not Published Loader Breakout Force 825TL NSL: 2,976 lb; 825TL MSL: 3,284 lb; 835TL NSL: 3,725 lb; 835TL MSL: 4,100 lb Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
