▶ EngineEngine Manufacturer FPT FPT Engine Model F5D F5 Engine Type 4-cylinder diesel Turbocharged 4-cylinder diesel No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 114 hp 112 hp PTO Power 98 hp 92 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Not Published Alternator 120 A 120 A ▶ HydraulicsPump Type Gear pumps Not Published Implement Flow T5.115: 16.1 gpm (21.1 gpm optional); T5.115 Electro Command: 21.1 gpm (16.1 gpm optional) 16.9 gpm (21.6 gpm optional) Steering Flow T5.115: 10.0 gpm (11.4 gpm optional); T5.115 Electro Command: 11.4 gpm (10.0 gpm optional) 9.7 gpm Total Hydraulic Flow T5.115: 26.1 gpm (16.1 + 10.0, computed); T5.115 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 26.6 gpm (16.9 + 9.7, computed) Overall Hydraulic Pump Flow T5.115: 26.1 gpm (16.1 + 10.0, computed); T5.115 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 26.6 gpm (16.9 + 9.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (3 optional) 2 or 3 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 37 gal ROPS: 24 gal; Cab: 29 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic clutch Wet clutch PTO with electro-hydraulic engagement PTO Rear 540/1000 540 (base); 540/540E or 540/1000 (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II/I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) T5.115: 6,393 lb (10,452 lb with 2 optional rams); T5.115 Electro Command: 6,393 lb (8,809 lb with 1 optional ram, 10,452 lb with 2) 3,200 lb (6,200 lb with optional ram) Lift Control Type Electronic draft control Lift-O-Matic 3-point quick raise system ▶ Transmission & DrivetrainTransmission Type T5.115: 12x12 power shuttle (standard), 20x20 power shuttle with creeper or 24x24 Dual Command power shuttle (optional); T5.115 Electro Command: 16x16 power shuttle (standard), 32x32 power shuttle with creeper (optional) 12x12 power shuttle No. of Speeds T5.115: 12F/12R (20F/20R or 24F/24R optional); T5.115 Electro Command: 16F/16R (32F/32R optional) 12F/12R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock; limited slip front Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc Wet disc Seat Suspension & Adjustability Numerous seat options including a premium low-frequency heated air-suspension seat; full-size instructor seat available Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: vinyl air-suspension seat Front Axle Type Heavy-duty 4WD front axle (standard) 4WD front axle, electro-hydraulic engagement (standard) Front Axle Rating 4,500 lb (in-action capacity at 4 mph) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch T5.115: 163.8 in; T5.115 Electro Command: 165.0 in 161.1 in (4WD) Overall Width 82.6 in Not Published Wheelbase 92.5 in Cab: 88.9 in; ROPS: 83.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 103.0 in Height to Top of ROPS (folded) Not Published Low-Profile ROPS: 68.4 in to ROPS pivot (500/60-22.5 R1 tires); 71.9 in (19.5L24 R4 tires) Height to Top of Cab Model T5.115: 105.4 in; T5.115 Electro Command: 105.6 in (non-suspended cab), 107.2 in (suspended cab) 105.4 in ▶ WeightTractor Weight (Base) T5.115: 9,370 lb; T5.115 Electro Command: 9,700 lb Cab/4WD: 8,367 lb; ROPS/4WD: 7,738 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 agricultural, R3 turf or R4 industrial R1 Agricultural - Front Not Published 12.4x24 (with 18.4x30 rear); 11.2-24 (with 16.9-30 rear); 11.5/80-18 (with 500/60-22.5 low-profile rear) R1 Agricultural - Rear Not Published 18.4x30 (standard); 16.9-30 or 500/60-22.5 low-profile (optional) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L24 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or European-style Skid-steer style (84 in bucket standard); Euro-style quick attach available Loader Model 825TL; 835TL (each NSL or MSL) 632TL (NSL); 637TL (MSL) Loader Lift Height 825TL: 138 in; 835TL: 146 in 632TL: 134.5 in; 637TL: 134.5 in Loader Lift Capacity (Full Height) 825TL NSL: 2,843 lb; 825TL MSL: 2,954 lb; 835TL NSL: 3,483 lb; 835TL MSL: 3,681 lb 632TL: 2,028 lb; 637TL: 3,174 lb (at 31.5 in from bucket pivot pin to max height) Loader Breakout Force 825TL NSL: 2,976 lb; 825TL MSL: 3,284 lb; 835TL NSL: 3,725 lb; 835TL MSL: 4,100 lb Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
