5,620 lb (7,351 lb with optional auxiliary lift ram)
Lift Control Type
Electronic draft control (EDC)
Mechanical draft and position control (12x12 models); Electronic Draft Control (EDC) with fender switches (Dual Command cab models); Lift-O-Matic Plus single-lever control (optional on 12x12, standard on Dual Command ROPS)
12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command Hi-Lo powershift with electrohydraulic power shuttle, or 40x40 Dual Command with creeper (optional)
No. of Speeds
Dynamic Command: 24F/24R; Auto Command: infinitely variable
12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional)
Comfort seat, low-frequency suspension, cloth (standard); Dynamic Comfort or Auto Comfort seats with heating and active ventilation (optional); instructor seat optional
Cab: fabric mechanical-suspension seat or fabric air-suspension seat with swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests
Front Axle Type
Class 1.75 heavy-duty 4WD front axle (standard); Terraglide front axle suspension (optional)
Heavy-duty electronically engaged 4WD front axle (standard); standard-duty electronically or mechanically engaged 4WD, or heavy-duty 2WD front axle (optional)
Front Axle Rating
Not Published
9,479 lb (standard-duty 4WD, in-action capacity at 4 mph); 10,361 lb (heavy-duty 4WD, in-action capacity at 4 mph)
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
173 in (max, weight carrier to rear linkage)
163.1 in (2WD); 160.9 in (4WD)
Overall Width
74 in (narrow); 90 in (standard)
75.7 in
Wheelbase
98 in
92.2 in (2WD); 89.9 in (4WD)
Ground Clearance
Not Published
Not Published
Min. Turn Radius without Brakes
182 in (4WD / Terraglide suspended front axle; brake use not stated)
134 in (2WD heavy-duty front axle)
Height to Top of ROPS
Not Published
106.5 in
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
106 in (low-profile roof, 540/65R34 tires)
102.1 in
Tractor Weight (Base)
12,125 lb (minimum shipping weight, cab)
6,988 lb (2WD ROPS); 7,672 lb (4WD ROPS)
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
Not Published
Ag: 16.9-30 rear with 11.2-24 front; 16.9-34 rear with 13.6-24 front; 18.4-30 rear with 12.4-24 front; 18.4-34 rear with 14.9-24 front. Turf: 16.9-24 rear with 13.6-16.1 front. Industrial: 19.5L24 rear with 12.5/80-18 front
R1 Agricultural - Front
Not Published
4WD: 11.2-24, 13.6-24, 12.4-24 or 14.9-24 (paired with 16.9-30, 16.9-34, 18.4-30 or 18.4-34 rears)
R1 Agricultural - Rear
Not Published
16.9-30, 16.9-34, 18.4-30 or 18.4-34
R3 Turf - Front
Not Published
13.6-16.1
R3 Turf - Rear
Not Published
16.9-24
R4 Industrial - Front
Not Published
12.5/80-18
R4 Industrial - Rear
Not Published
19.5L24
Quick Attach Loader System
Not Published
Skid-steer-style or Euro-style quick attach faceplate
Loader Model
800TL Series (wide frame)
Factory-fit: 655TL (NSL or MSL), 665TL (NSL or MSL); field-fit: 632TL (NSL), 637TL (MSL)
