▶ EngineEngine Manufacturer FPT Mahindra Engine Model NEF Not Published Engine Type 4-cylinder, 16-valve, turbocharged and intercooled, common-rail diesel, electronic fuel delivery control 4-cylinder, liquid-cooled inline diesel No. of Cylinders 4 4 Displacement 274 in³ 215.6 in³ Rated Engine Speed 2100 rpm 2300 rpm Engine Power (Gross) 125 hp 125 hp PTO Power 105 hp 106 hp Engine Emissions Constraints Stage V/Final Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Not Published Fuel System High-pressure common-rail, electronic fuel delivery control Common Rail Diesel Technology (mCRD) Alternator 150 A Not Published ▶ HydraulicsPump Type Electro Command: fixed-displacement gear pump (CCLS optional); Dynamic Command, Auto Command: closed-center load-sensing (CCLS) pump Not Published Implement Flow Value: 21.1 gpm; Plus, Elite: 29.9 gpm 21.2 gpm Steering Flow 12.4 gpm (17.2 gpm optional pump with Class 4 front axle) 9.25 gpm Total Hydraulic Flow Value: 33.5 gpm (21.1 + 12.4, computed); Plus, Elite: 42.3 gpm (29.9 + 12.4, computed) Not Published Overall Hydraulic Pump Flow Value: 33.5 gpm (21.1 + 12.4, computed); Plus, Elite: 42.3 gpm (29.9 + 12.4, computed) Not Published Hydraulic System Type Electro Command: fixed displacement, closed-center (CCLS optional); Dynamic Command: closed-center load-sensing (CCLS); Auto Command: CCLS Open center, position and draft control, telescoping stabilizers and flex links Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 mechanical (Value, Plus, Elite) 2 (9125 S); 3 (9125 P) No. of Optional Remote Valves Rear: 3 or 4 mechanical, or 3 or 4 electro-hydraulic (Elite); mid-mount: 2 or 3, mechanical or electronic One (3rd outlet on S models; 4th outlet on P model) ▶ Fluid CapacityFuel Tank Capacity 52.2 gal (58.6 gal with auxiliary tank); Dynamic Command: 60 gal Not Published Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, direct-drive PTO with push-pull engagement and Soft Start; reversible PTO shaft Independent PTO Rear 540/1000 rpm (540 at 1969 engine rpm, 1000 at 1893 engine rpm) 540 @ 2220 rpm, 1000 @ 2227 rpm (9125 S); 540 @ 2220 rpm, 750 @ 2208 rpm, 1000 @ 2227 rpm (9125 P) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Not Published Category II with telescopic link ends Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) Value: 8,338 lb; Auto Command: 9,214 lb; Plus, Elite and Auto Command with optional larger rams: 11,649 lb 5,787 lb (9125 S); 7,628 lb (9125 P) Lift Control Type Electronic draft control Electronic draft control with fender switches ▶ Transmission & DrivetrainTransmission Type Electro Command: 16x16 semi-powershift (standard), with 17x16 economy, 17x16 31 mph, 32x32 creeper and auto-shift options; Dynamic Command: 23x23 semi-powershift, with 24x24 economy, 31 mph and creeper options Power shuttle with synchromesh No. of Speeds Electro Command: 16F/16R, or 17F/16R economy or high-speed, 32F/32R with creeper; Dynamic Command: 23F/23R, or 24F/24R optional 12F / 12R (9125 S); 24F / 24R + 8 creepers (9125 P) Max Travel Speed (Forward) 25 mph (Electro Command 16x16 and Dynamic Command 23x23 standard); 31 mph (17x16 high-speed and Dynamic Command 24x24 31 mph options, FWD only); 19 mph (2WD) Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Terralock automatic traction management: automatic four-wheel drive engagement and front and rear differential locks Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Not Published Wet disc Seat Suspension & Adjustability Standard: low-frequency suspension seat; optional: heated low-frequency suspension seat, or heated and ventilated active-suspension seat; swiveling backrest; suspended cab optional Seat with adjustable air-suspension, folding adjustable armrest, recline and adjustable headrest Front Axle Type Standard FWD axle (Class 3 and 4); optional: Terraglide suspended FWD axle or SuperSteer FWD axle; heavy-duty 2WD axle available on Electro Command Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 89.8 in (minimum; 91 in with 650/65R38 tires) 91.3 in Wheelbase Standard FWD axle: 104 in; Terraglide suspended axle: 105.7 in; SuperSteer axle: 109.8 in; 2WD: 96 in Not Published Ground Clearance 18.8 in (18.4R38, 520/70R38 or 600/65R38 rear tires; 16.8 in with 16.9R38, 20.8 in with 650/65R38) Not Published Min. Turn Radius without Brakes 15.1 ft (standard FWD axle, 55 degree turn angle); 14.1 ft (2WD or SuperSteer axle, 65 degree turn angle) Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 115.2 in (standard cab, 18.4R38 tires); 110.4 in (low profile cab); 117.7 in (suspended cab) 107 in Overall Length 204.3 in (front linkage to rear linkage) 169.3 in ▶ WeightTractor Weight (Base) 10,560 lb (minimum shipping weight, cab FWD, less ballast) 9,385 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 16.9R38, 18.4R38, 520/70R38, 600/65R38, 650/65R38 (suspended cab only), 480/70R38, 540/65R38 or 650/60R38 with matching front tires Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear 18.4R38 (reference tire; also 16.9R38, 520/70R38, 600/65R38, 650/65R38, 480/70R38, 540/65R38, 650/60R38) Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Euro style (850LA, 855LA, 857LA); Euro or skid steer style (810LA) Skid steer style quick attach couplers Loader Model FWD: 850LA (NSL), 855LA (MSL); SuperSteer FWD: 857LA (MSL); 2WD: 810LA (NSL) 9125L Loader Lift Height 850LA: 13.5 ft; 855LA: 13.5 ft; 857LA: 13.9 ft; 810LA (2WD): 11.9 ft (to pivot pin, base equipment tires) 162 in Loader Lift Capacity (Full Height) 850LA: 2,932 lb; 855LA: 5,202 lb; 857LA: 4,365 lb; 810LA (2WD): 2,380 lb (to maximum height, measured 31.5 in forward of the pivot pin, with rear counterbalance) 5,415 lb (at pivot pin) Loader Breakout Force 850LA: 4,673 lb; 855LA: 5,974 lb; 857LA: 4,894 lb; 810LA (2WD): 3,439 lb (measured 31.5 in forward of the pivot pin) 6,874 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
