New Holland T6.155 vs New Holland T5.140 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Terralock automatic traction management: automatic 4WD engagement and front and rear differential locks
Terralock Auto Diff and Auto 4WD (standard); electro-hydraulic front and rear differential lock
Frame Type
Not Published
Not Published
Steering
Not Published
Power steering
Brakes
Not Published
Hydraulic wet disc
Seat Suspension & Adjustability
Comfort seat with low-frequency suspension standard; Dynamic Comfort seat (low-frequency suspension, heated) and Auto Comfort seat (active suspension, heated and ventilated) optional; swiveling backrest; Comfort Ride cab suspension optional
Comfort seat, low-frequency suspension, cloth (standard); Dynamic Comfort or Auto Comfort seats with heating and active ventilation (optional); instructor seat optional
Front Axle Type
Standard FWD axle (Class 3 and 4); Terraglide suspended FWD axle or SuperSteer FWD axle optional; heavy-duty 2WD axle available on Electro Command models
Class 1.75 heavy-duty 4WD front axle (standard); Terraglide front axle suspension (optional)
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
204.3 in (front linkage to rear linkage)
173 in (max, weight carrier to rear linkage)
Overall Width
89.8 in (minimum; 91 in with 650/65R38 tires)
74 in (narrow); 90 in (standard)
Wheelbase
Standard FWD axle: 104 in; Terraglide suspended axle: 105.7 in; SuperSteer axle: 109.8 in; 2WD: 96 in
98 in
Ground Clearance
18.8 in (18.4R38, 520/70R38 or 600/65R38 rear tires; 16.8 in with 16.9R38, 20.8 in with 650/65R38)
Not Published
Min. Turn Radius without Brakes
15.1 ft (standard FWD axle, 55 degree turn angle); 14.1 ft (2WD or SuperSteer axle, 65 degree turn angle)
182 in (4WD / Terraglide suspended front axle; brake use not stated)
Height to Top of ROPS
Not Published
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
115.2 in (standard cab, 18.4R38 tires); 110.4 in (low profile cab); 117.7 in (Comfort Ride suspension cab)
106 in (low-profile roof, 540/65R34 tires)
Tractor Weight (Base)
10,560 lb (minimum shipping weight, cab FWD, less ballast; average 11,376 lb, maximum 12,513 lb; 2WD is 1,234 lb less)
12,125 lb (minimum shipping weight, cab)
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
Rear: 16.9R38, 18.4R38, 520/70R38, 600/65R38, 650/65R38 (Comfort Ride cab only), 480/70R38, 540/65R38 or 650/60R38 with matching front tires
