▶ EngineEngine Manufacturer Shibaura Kubota Engine Model Not Published F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 Engine Type 3-cylinder diesel 3-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel No. of Cylinders 3 3 Displacement 91.3 in³ 111.4 in³ Rated Engine Speed 2800 rpm 2700 rpm Engine Power (Gross) 33 hp 33 hp PTO Power Manual: 28.6 hp; Hydrostatic: 26.9 hp F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled, water with pressurized radiator Air Cleaner Not Published Dry paper single element Fuel System Not Published Common-rail, direct injection, electronic control Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump, gear type Implement Flow 7.6 gpm 6.3 gpm Steering Flow 5.1 gpm 3.8 gpm Total Hydraulic Flow 12.7 gpm 10.1 gpm Overall Hydraulic Pump Flow 12.7 gpm 10.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 3: self-canceling detent valve or float detent valve ▶ Fluid CapacityFuel Tank Capacity 7.3 gal 11.1 gal Coolant Capacity Not Published 6.3 qt Crankcase Capacity Not Published 7.1 qt Transmission / Hydraulic System Capacity Not Published F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal Front Axle Fluid Capacity Not Published 4.8 qt ▶ PTO & HitchPTO Type Live F (2WD gear), DT (4WD gear): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running PTO Rear 540 rpm (live) 540 rpm Mid-PTO Availability Manual: transmission-driven 2000 rpm (DIA); Hydrostatic: live 2000 rpm No mid-PTO offered Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 1,874 lb (at lift points) Hitch Lift Capacity (at 24”) 1,635 lb 1,433 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Manual: 9x3 gear; Hydrostatic: 3-range hydrostatic F (2WD gear), DT (4WD gear): manual transmission with synchronized shuttle; HST (4WD): hydrostatic transmission No. of Speeds Manual: 9F/3R; Hydrostatic: 3 ranges F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Max Travel Speed (Forward) Manual: 12.8 mph; Hydrostatic: 14.3 mph F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Max Travel Speed (Reverse) Not Published F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph Clutch Not Published Dry type single stage Differential Lock & Limited Slip Options Rear differential lock (heel pedal) Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (factory certified) with retractable seat belt Steering Power steering Integral power steering Brakes Wet disc Mechanical wet disc type, pedals can be locked together Seat Suspension & Adjustability Not Published Not Published Front Axle Type FWD (standard); SuperSteer FWD with Sensitrak clutch (optional) F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing Front Axle Rating Not Published 2,865 lb (at 41.3 in tread, 2WD and 4WD models) Drawbar Capacity Not Published 730 lb ▶ Dimensions & ManeuverabilityOverall Width 54.3 in 55.1 in Wheelbase FWD: 63.0 in; SuperSteer FWD: 72.0 in 63.3 in Ground Clearance 14.0 in F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in Min. Turn Radius without Brakes FWD: 96.5 in; SuperSteer FWD: 93.8 in (with brake applied) F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft Height to Top of ROPS 87.8 in 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length FWD: 106.2 in; SuperSteer FWD: 115.3 in (with 3-point hitch) F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) FWD: 2,474 lb (shipping weight); SuperSteer FWD: 2,588 lb (shipping weight) F (2WD gear): 2,557 lb; DT (4WD gear): 2,734 lb; HST (4WD): 2,778 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Turf (including Galaxy Turf Special), R4 Industrial; FWD only (2WD not available) R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural - Front 7x14 (FWD) F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 R1 Agricultural - Rear 11.2x24 11.2-24 R3 Turf - Front 24x8.50-14 (FWD); Galaxy 25/10.50LLx15 F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 R3 Turf - Rear 13.6x16; Turf Special 41/18LLx16.1 13.6-16 R4 Industrial - Front 25x8.50-14 27x8.5-15 (4WD) R4 Industrial - Rear 15x19.5 15-19.5 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA525: 2-lever quick coupler, tool-free attach and detach Loader Model 7308 LA525 Loader Lift Height 7308: 100.8 in LA525: 94.3 in (at pivot pin) Loader Lift Capacity (Full Height) 7308: 875 lb LA525: 1,131 lb (at pivot pin, maximum height) Loader Breakout Force 7308: 2,344 lb LA525: 2,462 lbf (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published 24 months or 1500 hours (general)
