New Holland TC45DA vs Mahindra 5145 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
CAT I & II with telescopic stabilizers & flex links
Hitch Lift Capacity
Not Published
Not Published
Hitch Lift Capacity (at 24”)
2,330 lb
3,748 lb
Lift Control Type
Deluxe three-point hitch with flexible link ends, telescoping stabilizers, swinging drawbar and crank-style leveling (most models)
Position control
Transmission Type
2-range hydrostatic with DualPower Hi/Lo powershift
Full synchromesh with forward/reverse synchro shuttle and constant-mesh range
No. of Speeds
2 hydrostatic ranges, each with DualPower High/Low
12F / 12R
Max Travel Speed (Forward)
Not Published
17.9 mph
Max Travel Speed (Reverse)
Not Published
Not Published
Clutch
Not Published
Dual dry with cerametallic lining
Differential Lock & Limited Slip Options
Mechanical rear differential lock
Not Published
Frame Type
Not Published
Not Published
Steering
Hydrostatic power steering
Power steering with tilt steering wheel
Brakes
Wet disc
Fully-enclosed, 7-in diameter, dry disc
Seat Suspension & Adjustability
Seat on an inclined sliding track, three inches of vertical suspension, swivels up to 20° (5 positions); cab: cloth seat with weight-adjustable suspension
Adjustable seat with contoured cushions, armrests and a soft-coil suspension
Front Axle Type
FWD (standard); SuperSteer FWD with Sensitrak automatic FWD (optional); 2WD not available
Not Published
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Width
66.6 in (ag tires)
74.8 in
Wheelbase
FWD: 73.5 in; SuperSteer FWD: 81.0 in
77.9 in
Ground Clearance
Not Published
15.2 in
Min. Turn Radius without Brakes
Not Published
10.8 ft (3.29 m)
Height to Top of ROPS
95 in
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
90.1 in (R4 tires)
Not Published
Overall Length
FWD: 125.2 in (with 3-point hitch); SuperSteer FWD: 129.5 in
