▶ EnginePTO Power 65 hp (48.5 kW) 65 hp (48 kW) Alternator Not Published Not Published Air Cleaner Not Published Not Published Engine Type Turbocharged intercooled diesel 4-cylinder diesel, Smart Wastegate Turbo, intercooled Fuel System High pressure Common Rail Common-rail fuel-injection Displacement 207 cu in (3400 cc) 207 cu in (3.4 L) No. of Cylinders 4 4 Rated Engine Speed 2300 rpm 2,300 rpm Cooling System Type Liquid-cooled Liquid-cooled Engine Manufacturer FPT Industrial FPT Industrial Engine Emissions Constraints Tier 4A / Stage IIIB CEGR Tier 4A CEGR + DOC Engine Power (Gross vs. Net HP) 75 hp (55 kW) SAE: 74 hp (55 kW) ▶ WeightTractor Weight with Loader Not Applicable Not Published Weight with Cab and Loader Not Applicable Not Published Weight with ROPS and Loader Not Applicable Not Published ▶ HydraulicsPump Type Not Published Dual-pump (two separate open-center circuits) Steering Flow Not Published 35 L/min (9.2 gpm) Implement Flow 35.5 L/min (9.4 gpm) 64 L/min (16.9 gpm) Total Hydraulic Flow Not Published 99 L/min (26.1 gpm) Hydraulic System Type Open center Open center (two separate circuits) Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published 99 L/min (26.1 gpm) No. of Optional Remote Valves 4 3 No. of Standard Remote Valves Not Published 2 ▶ Tire OptionsR3 Turf - Rear Not Applicable Not Published R3 Turf - Front Not Applicable Not Published Tire Size & Options Not Applicable Not Published R4 Industrial - Rear Not Applicable Not Published R4 Industrial - Front Not Applicable Not Published R1 Agricultural - Rear Not Applicable Not Published R1 Agricultural - Front Not Applicable Not Published ▶ Pto & HitchPTO Rear 540/540E (Std); 540/1000 (Opt) 540/540E PTO Type Fully independent Servo-assisted engagement Lift Control Type Lift-O-Matic Lift-O-Matic™ Hitch Lift Capacity 7,793 lb (3,535 kg) 5,732 lb (2,600 kg) Mid-PTO Availability Not Applicable Not Published Category, 3-Point Hitch Not Published Category I & II Hitch Lift Capacity (at 24”) Not Published 4,045 lb (1,835 kg) Rear 3-Point Hitch Lift Capacity 7,793 lb (3,535 kg) 5,732 lb (2,600 kg) ▶ Fluid CapacityCoolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Fuel Tank Capacity 21.1 gal (80 L) 25 gal (95 L) Front Axle Fluid Capacity Not Applicable Not Published Transmission / Hydraulic System Capacity Not Published Not Published ▶ Loader & AttachmentsLoader Lift Height Not Applicable Not Published Loader Breakout Force Not Applicable Not Published Price for Backhoe Option Not Applicable Not Published Price for Mid-Mount Mower Not Applicable Not Published Quick Attach Loader System Not Applicable Not Published Loader Lift Capacity (Full Height) Not Applicable Not Published ▶ Transmission & DrivetrainClutch Not Published Not Published No. of Speeds 8F/8R 16F/16R; 32F/16R Transmission Type Mechanical forward-reverse shuttle 16x16 Shuttle Command; 16x16 Power Shuttle; 32x16 Dual Command Max Travel Speed (Forward) 6.8 mph (11 km/h) Not Published Max Travel Speed (Reverse) 6.8 mph (11 km/h) Not Published Differential Lock & Limited Slip Options Not Applicable Electro hydraulic differential lock ▶ Chassis Steering & ControlsBrakes Not Published Oil immersed braking system Steering Steering-O-Matic; Steering-O-Matic Plus (optional) Not Published Frame Type Not Published Not Published Front Axle Type Not Applicable SuperSteer™ FWD axle Drawbar Capacity 1,323 lb (600 kg) vertical load Not Published Front Axle Rating Not Applicable Not Published Seat Suspension & Adjustability Air suspended seat (optional) Not Published ▶ Dimensions & ManeuverabilityWheelbase 52.8 in (1341 mm) 96 in (2435 mm) Overall Width 55.1-57.1 in (1400-1450 mm) 62 in (1569 mm) (minimum) Ground Clearance Not Published 10 in (242 mm) Height to Top of ROPS 94.1 in (2390 mm) 91 in (2313 mm) Height to Top of Cab Model Not Applicable 89 in (2265 mm) Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published 117 in (2980 mm) Overall Length with 3-Point Hitch 137.6 in (3495 mm) Not Published ▶ Pricing Financing & WarrantyFinancing Options Not Published Not Published Base Price with Loader Not Applicable Not Published Warranty Length & Coverage Not Published Not Published Base Price with Loader + Cab Not Applicable Not Published ▶ SourcesSpec sheet sources [1] cnhi-p-001-delivery.sitecorecontenthub.cloud [2] agriculture.newholland.com [1] cnhi-p-001-delivery.sitecorecontenthub.cloud
