▶ EngineEngine Manufacturer FPT AGCO Power Engine Model NEF 44 AWFC Engine Type 4-cylinder, 16-valve, turbocharged, air-to-air intercooled diesel with high-pressure common rail 4-cylinder, intercooled turbocharged, liquid-cooled diesel No. of Cylinders 4 4 Displacement 274 in³ 268.5 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 130 hp 120 hp PTO Power 112 hp 99 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid cooled Air Cleaner Not Published Not Published Fuel System High-pressure common rail fuel injection High-pressure common-rail direct injection (HPCR) Alternator 120 A 120 A, 12 V ▶ HydraulicsPump Type Fixed displacement pumps (steering, implement, auxiliary) with combining/diverter valve Two high-pressure gear pumps Implement Flow 19 gpm (combined implement and auxiliary pump flow) 15.1 gpm Steering Flow 9 gpm Not Published Total Hydraulic Flow 28 gpm 25.9 gpm Overall Hydraulic Pump Flow 28 gpm Not Published Hydraulic System Type Fixed displacement pumps with combining/diverter valve; deluxe closed-center rear remote valves with flow control Open center Rear Remote Hydraulic Flow Not Published 26 gpm No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 57.5 gal 38.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Not Published Independent, electro-hydraulic engagement via switch PTO Rear 540/1000 rpm 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (flex link ends) Category II Hitch Lift Capacity 3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two Not Published Hitch Lift Capacity (at 24”) Not Published 9,390 lb Lift Control Type Not Published Electronic linkage control (ELC) ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional 12F x 12R, 2-range power shuttle with electrohydraulic shuttle lever No. of Speeds 8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo) 12 forward, 12 reverse Max Travel Speed (Forward) 19 mph or 25 mph (25 mph 4WD only) 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Single-plate wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Not Published Rear differential lock engaged via electrohydraulic rocker switch; Hydra-Lock hydraulic front axle differential lock on 4WD ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering; cab: tilt and telescopic column, platform: tilt column Brakes Not Published Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Mechanical suspension seat standard; deluxe air suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab) Cab: air-ride swivel seat; platform: mechanical spring suspension seat with armrests Front Axle Type Heavy-duty front axle, 2WD or 4WD (both optional, cab only) Heavy-duty 4WD front axle: cast steel, fixed, center drive line, planetary final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 184.7 in (4WD, with front weights); 184.5 in (2WD, with front weights) Not Published Overall Width Not Published 64.8 in Wheelbase Not Published 98.4 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 110.2 in Not Published ▶ WeightTractor Weight (Base) 11,200 lb (shipping, 4WD, cab, flange axle); 12,192 lb (4WD, cab, bar axle); 9,921 lb (2WD, cab) 4WD ROPS: 9,371 lb; 4WD Cab: 10,187 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18.4-38 R1 rear with 14.9-28 R1 front (4WD) or 10.00-16 front (2WD) Rear: 460/85R34 standard radial R1 Agricultural - Front 14.9-28 (4WD); 10.00-16 (2WD) Not Published R1 Agricultural - Rear 18.4-38 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer (SSL) or Euro style attachment couplers Not Published Loader Model 4WD: 830LA (NSL), 835LA (MSL); 2WD: 810LA (NSL) 941X; 946X; FL.3723; FL.3819 Loader Lift Height 830LA: 150.0 in; 835LA: 150.0 in; 810LA (2WD): 144.0 in (to pivot pin) 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in Loader Lift Capacity (Full Height) 830LA: 2,557 lb; 835LA: 3,813 lb; 810LA (2WD): 2,094 lb (to maximum height, measured 31.5 in forward of the pivot pin) 941X: 3,650 lb; FL.3723: 4,519.5 lb Loader Breakout Force 830LA: 3,681 lb; 835LA: 3,968 lb; 810LA (2WD): 3,020 lb (measured 31.5 in forward of the pivot pin) FL.3723: 5,818.6 lb; FL.3819: 4,892.9 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
