▶ EngineEngine Manufacturer FPT AGCO Power Engine Model F36 33 AWI HD Engine Type 4-cylinder 3-cylinder turbocharged and intercooled diesel No. of Cylinders 4 3 Displacement Not Published 201 in³ Rated Engine Speed Not Published 2200 rpm Engine Power (Gross) 101 hp 100 hp PTO Power 85 hp 75 hp Engine Emissions Constraints Not Published Tier 4i Cooling System Type Not Published Water-cooled Air Cleaner Not Published 2-stage dry Fuel System Not Published Common rail direct injection Alternator Not Published 120 A ▶ HydraulicsPump Type Not Published Single gear pump; tandem gear pumps optional Implement Flow Not Published 15 gpm standard; 26 gpm with optional Twin Flow Steering Flow Not Published Not Published Total Hydraulic Flow 26.6 gpm 26 gpm (tandem pumps: 15 gpm to the 3-point hitch plus 11 gpm to remotes, combinable) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 15 gpm standard; 26 gpm with optional Twin Flow No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published Up to 4 ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 42 gal Coolant Capacity Not Published 15.3 qt Crankcase Capacity Not Published 13.7 qt Transmission / Hydraulic System Capacity Not Published 17.2 gal Front Axle Fluid Capacity Not Published 5.3 qt axle beam; 0.85 qt each final drive ▶ PTO & HitchPTO Type Not Published Independent, electro-hydraulic engagement and speed selection PTO Rear Not Published 540/540E standard; 540/540E/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Not Published Category II Hitch Lift Capacity Not Published 9,480 lb Hitch Lift Capacity (at 24”) Not Published 7,100 lb Lift Control Type Not Published Electronically operated, lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type 12x12 electronic power shuttle Dyna-4 16x16 power shift and power shuttle (AUTO-DRIVE optional, 14:1 creeper optional) No. of Speeds 12 forward / 12 reverse 16F / 16R Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Wet multi-disc, foot pedal and electronic control Differential Lock & Limited Slip Options Not Published Fully locking front and rear axle differentials, electro-hydraulically engaged ▶ Chassis, Steering & ControlsFrame Type Not Published Rigid structural chassis; solid cast-steel flanged rear axle, internal planetary reduction Steering Not Published Hydrostatic power steering Brakes Not Published Internal wet disc, hydraulic power assist, individual left and right foot pedals Seat Suspension & Adjustability Air ride seat (standard); instructor seat available Mechanical suspended swivel seat, standard; manual or automatic air-suspension, optional Front Axle Type Class 1.0 HD heavy-duty front axle Adjustable 2WD, or fixed cast-steel 4WD (single-piece), outboard planetary final drives Front Axle Rating Not Published 2WD: 6,085 lb; 4WD: 10,500 lb Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 79.3 in Wheelbase Not Published 97.1 in Ground Clearance Not Published 17.6 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 111.3 in (16.9R38 rear tires) Overall Length Not Published 167.5 in ▶ WeightTractor Weight (Base) Not Published 2WD: 8,426 lb; 4WD: 8,978 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 radial agricultural tires only; 16.9R38 rear is the speed chart basis (16.9R34, 16.9R30, 18.4R30, 18.4R34, 13.6R38 listed) R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published 16.9R38 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published MF931, MF941, MF946: quick attachment, single lever locking system Loader Model 630LU; 635LU MF931, MF941, MF946 Loader Lift Height 143.9 in (630LU and 635LU) MF931: 138 in; MF941: 148 in; MF946: 148 in (at pivot pins) Loader Lift Capacity (Full Height) 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, @ 31.5 in) MF931: 3,880 lb; MF941: 4,735 lb; MF946: 3,965 lb (at pivot) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published 2-year/2,000-hour full coverage, all parts and labor
