▶ EngineEngine Manufacturer FPT AGCO Power Engine Model F5 44 AWFC Engine Type Turbocharged 4-cylinder diesel 4-cylinder, intercooled turbocharged, liquid-cooled diesel No. of Cylinders 4 4 Displacement 207 in³ 268.5 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 112 hp 110 hp PTO Power 92 hp Power Shuttle: 93 hp; Dyna-4: 86 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Not Published High-pressure common-rail direct injection (HPCR) Alternator 120 A 120 A, 12 V ▶ HydraulicsPump Type Not Published Two high-pressure gear pumps Implement Flow 16.9 gpm (21.6 gpm optional) 15.1 gpm Steering Flow 9.7 gpm Not Published Total Hydraulic Flow 26.6 gpm (16.9 + 9.7, computed) 25.9 gpm Overall Hydraulic Pump Flow 26.6 gpm (16.9 + 9.7, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 26 gpm No. of Standard Remote Valves 2 or 3 2 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity ROPS: 24 gal; Cab: 29 gal 38.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Wet clutch PTO with electro-hydraulic engagement Independent, electro-hydraulic engagement via switch PTO Rear 540 (base); 540/540E or 540/1000 (optional) 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,200 lb (6,200 lb with optional ram) 7,710 lb Lift Control Type Lift-O-Matic 3-point quick raise system Electronic linkage control (ELC) ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle Power Shuttle: 12F x 12R, 2-range with electrohydraulic shuttle lever; Dyna-4: 16F x 16R powershift No. of Speeds 12F/12R Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Single-plate wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Not Published Rear differential lock engaged via electrohydraulic rocker switch; Hydra-Lock hydraulic front axle differential lock on 4WD ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering; cab: tilt and telescopic column, platform: tilt column Brakes Wet disc Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: vinyl air-suspension seat Cab: air-ride swivel seat; platform: mechanical spring suspension seat with armrests Front Axle Type 4WD front axle, electro-hydraulic engagement (standard) Heavy-duty 4WD front axle: cast steel, fixed, center drive line, planetary final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 161.1 in (4WD) Not Published Overall Width Not Published 64.8 in Wheelbase Cab: 88.9 in; ROPS: 83.7 in 95.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 103.0 in Not Published Height to Top of ROPS (folded) Low-Profile ROPS: 68.4 in to ROPS pivot (500/60-22.5 R1 tires); 71.9 in (19.5L24 R4 tires) Not Published Height to Top of Cab Model 105.4 in Not Published ▶ WeightTractor Weight (Base) Cab/4WD: 8,367 lb; ROPS/4WD: 7,738 lb 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf or R4 industrial Rear: 460/85R34 standard radial R1 Agricultural - Front 12.4x24 (with 18.4x30 rear); 11.2-24 (with 16.9-30 rear); 11.5/80-18 (with 500/60-22.5 low-profile rear) Not Published R1 Agricultural - Rear 18.4x30 (standard); 16.9-30 or 500/60-22.5 low-profile (optional) Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style (84 in bucket standard); Euro-style quick attach available Not Published Loader Model 632TL (NSL); 637TL (MSL) 941X; 946X; FL.3723; FL.3819 Loader Lift Height 632TL: 134.5 in; 637TL: 134.5 in 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in Loader Lift Capacity (Full Height) 632TL: 2,028 lb; 637TL: 3,174 lb (at 31.5 in from bucket pivot pin to max height) 941X: 3,650 lb; FL.3723: 4,519.5 lb Loader Breakout Force Not Published FL.3723: 5,818.6 lb; FL.3819: 4,892.9 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
