New Holland Workmaster 105 vs New Holland T4.120 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
5,620 lb (7,351 lb with optional auxiliary lift ram)
Lift Control Type
Lift-O-Matic 3-point quick raise system
Mechanical draft and position control (12x12 models); Electronic Draft Control (EDC) with fender switches (Dual Command cab models); Lift-O-Matic Plus single-lever control (optional on 12x12, standard on Dual Command ROPS)
Transmission Type
12x12 power shuttle
12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command Hi-Lo powershift with electrohydraulic power shuttle, or 40x40 Dual Command with creeper (optional)
No. of Speeds
12F/12R
12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional)
Max Travel Speed (Forward)
Not Published
20 mph (12x12 and 20x20 creeper, standard; 25 mph transport option); 25 mph (24x24 and 40x40 Dual Command)
Cab: fabric mechanical-suspension seat or fabric air-suspension seat with swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests
Front Axle Type
4WD front axle, electro-hydraulic engagement (standard)
Heavy-duty electronically engaged 4WD front axle (standard); standard-duty electronically or mechanically engaged 4WD, or heavy-duty 2WD front axle (optional)
Front Axle Rating
Not Published
9,479 lb (standard-duty 4WD, in-action capacity at 4 mph); 10,361 lb (heavy-duty 4WD, in-action capacity at 4 mph)
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
161.1 in (4WD)
163.1 in (2WD); 160.9 in (4WD)
Overall Width
Not Published
75.7 in
Wheelbase
Cab: 88.9 in; ROPS: 83.7 in
92.2 in (2WD); 89.9 in (4WD)
Ground Clearance
Not Published
Not Published
Min. Turn Radius without Brakes
Not Published
134 in (2WD heavy-duty front axle)
Height to Top of ROPS
103.0 in
106.5 in
Height to Top of ROPS (folded)
Low-Profile ROPS: 68.4 in to ROPS pivot (500/60-22.5 R1 tires); 71.9 in (19.5L24 R4 tires)
Not Published
Height to Top of Cab Model
105.4 in
102.1 in
Tractor Weight (Base)
Cab/4WD: 8,367 lb; ROPS/4WD: 7,738 lb
6,988 lb (2WD ROPS); 7,672 lb (4WD ROPS)
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
R1 agricultural, R3 turf or R4 industrial
Ag: 16.9-30 rear with 11.2-24 front; 16.9-34 rear with 13.6-24 front; 18.4-30 rear with 12.4-24 front; 18.4-34 rear with 14.9-24 front. Turf: 16.9-24 rear with 13.6-16.1 front. Industrial: 19.5L24 rear with 12.5/80-18 front
