▶ EngineEngine Manufacturer FPT FPT Engine Model F5 F5G Engine Type Turbocharged 4-cylinder diesel Dual Command: 4-cylinder diesel; Electro Command: 4-cylinder turbocharged diesel, high-pressure common rail, air-to-air intercooled No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 112 hp 107 hp PTO Power 92 hp 93 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Not Published Electro Command: high-pressure common rail with electronic fuel delivery control Alternator 120 A 120 A ▶ HydraulicsPump Type Not Published Fixed displacement, tandem pumps (implement and steering) Implement Flow 16.9 gpm (21.6 gpm optional) Dual Command: 16.9 gpm; Electro Command: 21.1 gpm Steering Flow 9.7 gpm Dual Command: 9.7 gpm; Electro Command: 11.4 gpm Total Hydraulic Flow 26.6 gpm (16.9 + 9.7, computed) Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Overall Hydraulic Pump Flow 26.6 gpm (16.9 + 9.7, computed) Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 or 3 Dual Command: 2 or 3; Electro Command: 2 No. of Optional Remote Valves Not Published Electro Command: 3 (plus 2 mid-mount) ▶ Fluid CapacityFuel Tank Capacity ROPS: 24 gal; Cab: 29 gal Electro Command: 43.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Wet clutch PTO with electro-hydraulic engagement Independent (hydraulic wet disc clutch) PTO Rear 540 (base); 540/540E or 540/1000 (optional) Dual Command: 540/1000 rpm (optional); Electro Command: 540/1000 rpm (540/540E/1000 optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category II Hitch Lift Capacity Not Published Dual Command: 5,620 lb (7,351 lb with optional ram); Electro Command: 8,084 lb Hitch Lift Capacity (at 24”) 3,200 lb (6,200 lb with optional ram) Dual Command: 5,620 lb (7,351 lb with optional ram) Lift Control Type Lift-O-Matic 3-point quick raise system Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle Dual Command: 24x24 Dual Command Hi-Lo with power shuttle (standard); Electro Command: 16x16 Electro Command semi-powershift (AutoShift or 32x32 creeper optional) No. of Speeds 12F/12R Dual Command: 24F/24R; Electro Command: 16F/16R (32F/32R with creeper) Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Electro-hydraulic rear differential lock; TerraLock automatic 4WD and differential lock engagement optional on Electro Command ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: vinyl air-suspension seat Not Published Front Axle Type 4WD front axle, electro-hydraulic engagement (standard) 4WD front axle, class 1.5 HD (TerraGlide suspended 4WD front axle optional on Electro Command) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 161.1 in (4WD) Dual Command: 160.9 in; Electro Command: 165 in Overall Width Not Published Dual Command: 75.7 in Wheelbase Cab: 88.9 in; ROPS: 83.7 in Dual Command: 89.9 in; Electro Command: 93.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 103.0 in Dual Command: 106.5 in Height to Top of ROPS (folded) Low-Profile ROPS: 68.4 in to ROPS pivot (500/60-22.5 R1 tires); 71.9 in (19.5L24 R4 tires) Not Published Height to Top of Cab Model 105.4 in Dual Command: 102.1 in; Electro Command: 107 in ▶ WeightTractor Weight (Base) Cab/4WD: 8,367 lb; ROPS/4WD: 7,738 lb Dual Command (ROPS): 7,672 lb; Dual Command (Cab): 8,157 lb; Electro Command (Cab): 10,031 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf or R4 industrial Not Published R1 Agricultural - Front 12.4x24 (with 18.4x30 rear); 11.2-24 (with 16.9-30 rear); 11.5/80-18 (with 500/60-22.5 low-profile rear) 14.9R24 R1 Agricultural - Rear 18.4x30 (standard); 16.9-30 or 500/60-22.5 low-profile (optional) 18.4R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style (84 in bucket standard); Euro-style quick attach available Skid-steer style or Euro (European) style tool carrier Loader Model 632TL (NSL); 637TL (MSL) 825TL; 835TL (each NSL or MSL); 810LA (NSL); 815LA (MSL) Loader Lift Height 632TL: 134.5 in; 637TL: 134.5 in 825TL: 139.0 in; 835TL: 146.9 in (to pivot pin) Loader Lift Capacity (Full Height) 632TL: 2,028 lb; 637TL: 3,174 lb (at 31.5 in from bucket pivot pin to max height) 825TL NSL: 2,954 lb; 825TL MSL: 3,086 lb; 835TL NSL: 3,638 lb; 835TL MSL: 3,836 lb (to max height, measured 31.5 in forward of pivot pin) Loader Breakout Force Not Published 825TL NSL: 3,109 lb; 825TL MSL: 3,417 lb; 835TL NSL: 3,880 lb; 835TL MSL: 4,277 lb (measured 31.5 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
