▶ EngineEngine Manufacturer FPT Doosan Infracore Engine Model F5 D34P Engine Type Turbocharged 4-cylinder diesel 4-cylinder, turbocharged diesel No. of Cylinders 4 4 Displacement 207 in³ 208 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 112 hp 110 hp PTO Power 92 hp 98.8 hp Engine Emissions Constraints Tier 4B Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dual dry Fuel System Not Published CRDI Alternator 120 A 110 A, 12 V ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 16.9 gpm (21.6 gpm optional) 14.1 gpm Steering Flow 9.7 gpm 7.1 gpm Total Hydraulic Flow 26.6 gpm (16.9 + 9.7, computed) 21.3 gpm Overall Hydraulic Pump Flow 26.6 gpm (16.9 + 9.7, computed) 21.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 or 3 3 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity ROPS: 24 gal; Cab: 29 gal 29.1 gal (DEF 5.3 gal) Coolant Capacity Not Published 17.4 qt Crankcase Capacity Not Published 16.8 qt Transmission / Hydraulic System Capacity Not Published 19.8 gal Front Axle Fluid Capacity Not Published 18.4 qt ▶ PTO & HitchPTO Type Independent wet clutch PTO, hydraulically engaged Independent PTO Rear 540 (base); 540/540E or 540/1000 (optional) 540/750/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category II Hitch Lift Capacity Not Published 6,860 lb Hitch Lift Capacity (at 24”) 3,200 lb (6,200 lb with optional ram) 5,490 lb Lift Control Type Lift-O-Matic rear hitch control Position/Draft/Elec ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle Power shuttle & Hi-Lo shift No. of Speeds 12F/12R F32 x R32 Max Travel Speed (Forward) Not Published 24.6 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Wet multi plate Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Wet disc Wet disc Seat Suspension & Adjustability Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: vinyl air-suspension seat Not Published Front Axle Type 4WD front axle, electronic engagement (standard) 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 86 in Wheelbase Cab: 88.9 in; ROPS: 83.7 in 90.6 in Ground Clearance Not Published 18.3 in Min. Turn Radius without Brakes Not Published 162 in Height to Top of ROPS 103.0 in Not Published Height to Top of ROPS (folded) Low-Profile ROPS: 68.4 in to ROPS pivot (500/60-22.5 R1 tires); 71.9 in (19.5L24 R4 tires) Not Published Height to Top of Cab Model 105.4 in 107 in Overall Length 161.1 in (4WD) 167.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) Cab/4WD: 8,367 lb; ROPS/4WD: 7,738 lb 8,929 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 rear: 18.4x30 (cab and all-purpose ROPS), 500/60-22.5 (low-profile ROPS); R4 rear: 19.5L24 Not Published R1 Agricultural - Front 12.4x24 (with 18.4x30 rear); 11.2-24 (with 16.9-30 rear); 11.5/80-18 (with 500/60-22.5 low-profile rear) FSTR 380/85R24 TL (14.9R24) R1 Agricultural - Rear 18.4x30 (cab and all-purpose ROPS); 500/60-22.5 (low-profile ROPS) FSTR 460/85R34 TL (18.4R34) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style (84 in bucket standard); Euro-style quick attach available Not Published Loader Model 632TL (NSL); 637TL (MSL) TX110SL Loader Lift Height 632TL: 134.5 in; 637TL: 134.5 in TX110SL: 144.4 in Loader Lift Capacity (Full Height) 632TL: 2,028 lb; 637TL: 3,174 lb (at 31.5 in from bucket pivot pin to max height) TX110SL: 4,129 lb (at pivot pin) Loader Breakout Force Not Published TX110SL: 6,025 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months
