▶ EngineEngine Manufacturer FPT FPT Engine Model F36 NEF Engine Type 4-cylinder 4-cylinder, 16-valve, turbocharged, air-to-air intercooled diesel with high-pressure common rail No. of Cylinders 4 4 Displacement Not Published 274 in³ Rated Engine Speed Not Published 2200 rpm Engine Power (Gross) 110 hp 110 hp PTO Power 93 hp 92 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Not Published Air Cleaner Not Published Not Published Fuel System Not Published High-pressure common rail fuel injection Alternator Not Published 120 A ▶ HydraulicsPump Type Not Published Fixed displacement pumps (steering, implement, auxiliary) with combining/diverter valve Implement Flow Not Published 19 gpm (combined implement and auxiliary pump flow) Steering Flow Not Published 9 gpm Total Hydraulic Flow 21 gpm 28 gpm Overall Hydraulic Pump Flow Not Published 28 gpm Hydraulic System Type Not Published Fixed displacement pumps with combining/diverter valve; deluxe closed-center rear remote valves with flow control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 57.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Not Published Not Published PTO Rear Not Published 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Not Published Category II (flex link ends) Hitch Lift Capacity Not Published 3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two Hitch Lift Capacity (at 24”) Not Published Not Published Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 electronic power shuttle 8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional No. of Speeds 12 forward / 12 reverse 8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo) Max Travel Speed (Forward) Not Published 19 mph or 25 mph (25 mph 4WD only) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Not Published Brakes Not Published Not Published Seat Suspension & Adjustability Air ride seat (standard); instructor seat available Mechanical suspension seat standard; deluxe air suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab) Front Axle Type Class 1.0 HD heavy-duty front axle 4WD heavy-duty front axle, Standard Duty Class 3 (cab and 4WD only) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 184.7 in (4WD, with front weights) Overall Width Not Published Not Published Wheelbase Not Published 99.2 in (4WD, Standard Duty Class 3 axle) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 110.2 in ▶ WeightTractor Weight (Base) Not Published 11,200 lb (shipping, 4WD, cab, flange axle); 12,192 lb (4WD, cab, bar axle) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 18.4-38 R1 rear with 14.9-28 R1 front (4WD) R1 Agricultural - Front Not Published 14.9-28 (4WD) R1 Agricultural - Rear Not Published 18.4-38 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid steer (SSL) or Euro style attachment couplers Loader Model 630LU; 635LU 830LA (NSL); 835LA (MSL) Loader Lift Height 143.9 in (630LU and 635LU) 830LA: 150.0 in; 835LA: 150.0 in (to pivot pin) Loader Lift Capacity (Full Height) 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, 31.5 in forward of the bucket pivot point) 830LA: 2,557 lb; 835LA: 3,813 lb (to maximum height, measured 31.5 in forward of the pivot pin) Loader Breakout Force Not Published 830LA: 3,681 lb; 835LA: 3,968 lb (measured 31.5 in forward of the pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
