▶ EngineEngine Manufacturer FPT Kubota Engine Model F36 V3800-TI-CRS Engine Type 4-cylinder 4-cylinder, turbocharged and intercooled, common-rail, liquid-cooled diesel No. of Cylinders 4 4 Displacement Not Published 230 in³ Rated Engine Speed Not Published 2600 rpm Engine Power (Gross) 117 hp 114.1 hp PTO Power 99 hp 92 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Liquid-cooled, pressurized radiator, recovery tank Air Cleaner Not Published 8 in dry, dual element Fuel System Not Published Common rail direct injection Alternator Not Published 130 A, 12 V ▶ HydraulicsPump Type Not Published Gear pumps Implement Flow Not Published 18.7 gpm Steering Flow Not Published 16.0 gpm Total Hydraulic Flow 26.6 gpm 34.7 gpm (18.7 + 16.0, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Not Published Pressure compensated, fixed displacement Rear Remote Hydraulic Flow Not Published 18.7 gpm No. of Standard Remote Valves Not Published 2 (with built-in flow control) No. of Optional Remote Valves Not Published 3rd and 4th optional (4 max) ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 50.2 gal Coolant Capacity Not Published 11.3 qt Crankcase Capacity Not Published 11.3 qt Transmission / Hydraulic System Capacity Not Published 17.2 gal Front Axle Fluid Capacity Not Published 7.2 qt (differential) plus 3.8 qt per bevel gear case ▶ PTO & HitchPTO Type Not Published Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear Not Published 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Not Published Category II Hitch Lift Capacity Not Published 8,598 lb Hitch Lift Capacity (at 24”) Not Published 6,834 lb (optional 9,447 lb) Lift Control Type Not Published Electronic draft control, lower-link sensing; left fender-mounted hitch switch standard ▶ Transmission & DrivetrainTransmission Type 12x12 electronic power shuttle 24F/24R powershift (8-speed main, 3-speed mechanical range, clutch button, microprocessor-controlled electro-hydraulic shuttle); 32F/32R optional with creep No. of Speeds 12 forward / 12 reverse 24F/24R (32F/32R with optional creep) Max Travel Speed (Forward) Not Published 23.4 mph Max Travel Speed (Reverse) Not Published 22.33 mph (with 18.4R38 tires, at rated rpm) Clutch Not Published Multiple wet disc, electro-hydraulically operated, 5.2 in Differential Lock & Limited Slip Options Not Published Electro-hydraulic front differential lock; rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Certified ROPS cab standard Steering Not Published Hydrostatic power steering Brakes Not Published Hydraulically operated wet disc brakes with automatic front axle engagement (4WD) Seat Suspension & Adjustability Air ride seat (standard); instructor seat available Air-suspension seat, swivel, reclining, fully adjustable (height, weight, fore-aft), armrests, retractable seat belt Front Axle Type Class 1.0 HD heavy-duty front axle 4WD, bevel-gear type, on-the-go electro-hydraulic engagement, electro-hydraulic front differential lock Front Axle Rating Not Published 6,610 lb at 62.2 in tread (9,700 lb with loader) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 82.7 in Wheelbase Not Published 95.9 in Ground Clearance Not Published 19.5 in (crop clearance) Min. Turn Radius without Brakes Not Published 13.1 ft (with Bi-Speed turn, 4WD on) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 111.8 in Overall Length Not Published 165.4 in ▶ WeightTractor Weight (Base) Not Published 9,788 lb (with standard tire) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Standard: 13.6 R24 front, 18.4 R34 rear (R1 options 12.4-24, 13.6-24 front; 16.9-34, 18.4R30, 18.4-34 rear) R1 Agricultural - Front Not Published 13.6 R24 R1 Agricultural - Rear Not Published 18.4 R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA1955: 2-lever quick coupler or Euro quick coupler; single-lever hydraulic quick coupler; quick attach/detach loader with boom stands, two mounting pins Loader Model 630LU; 635LU LA1955 Loader Lift Height 143.9 in (630LU and 635LU) LA1955 (height position): 145.7 in; LA1955 (power position): 132.7 in Loader Lift Capacity (Full Height) 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, @ 31.5 in) LA1955 (height position): 4,178 lb at pivot pin; LA1955 (power position): 4,299 lb at pivot pin Loader Breakout Force Not Published LA1955 (height position): 5,589 lbf at pivot pin; LA1955 (power position): 6,576 lbf at pivot pin ▶ WarrantyWarranty Length & Coverage Not Published Not Published
