▶ EngineEngine Manufacturer FPT FPT Engine Model F36 F5G Engine Type 4-cylinder Dual Command: 4-cylinder diesel; Electro Command: 4-cylinder, turbocharged and intercooled, common-rail diesel No. of Cylinders 4 4 Displacement Not Published 207 in³ Rated Engine Speed Not Published 2200 rpm Engine Power (Gross) 117 hp 117 hp PTO Power 99 hp Dual Command: 100 hp; Electro Command: 99 hp Engine Emissions Constraints Not Published Tier 4B/Final Cooling System Type Not Published Liquid cooled Air Cleaner Not Published Not Published Fuel System Not Published Electro Command: high-pressure common-rail, electronic fuel delivery control Alternator Not Published 120 A ▶ HydraulicsPump Type Not Published Fixed displacement, tandem pumps (implement and steering) Implement Flow Not Published Dual Command: 16.9 gpm; Electro Command: 21.1 gpm Steering Flow Not Published Dual Command: 9.7 gpm; Electro Command: 11.4 gpm Total Hydraulic Flow 26.6 gpm Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Overall Hydraulic Pump Flow Not Published Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Dual Command: 2 or 3; Electro Command: 2 No. of Optional Remote Valves Not Published Electro Command: 3 mechanical rear; mid-mount: 2 Function Mechanical or 2 Function Electronic ▶ Fluid CapacityFuel Tank Capacity 34.3 gal Electro Command: 43.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Not Published Independent (hydraulic wet disc clutch) PTO Rear Not Published Dual Command: 540/1000 rpm (optional); Electro Command: 540/1000 rpm (540/540E/1000 optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Not Published Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) Not Published Dual Command: 5,620 lb (7,351 lb with optional ram) Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 electronic power shuttle Dual Command: 24x24 Hi-Lo with power shuttle (standard); Electro Command: 16x16 semi-powershift (auto-shift or 32x32 creeper optional) No. of Speeds 12 forward / 12 reverse Dual Command: 24F/24R; Electro Command: 16F/16R (32F/32R with creeper) Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published TerraLock automatic 4WD engagement and differential lock system (optional on Electro Command) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Not Published Hydraulic wet disc Seat Suspension & Adjustability Air ride seat (standard); instructor seat available Not Published Front Axle Type Class 1.0 HD heavy-duty front axle 4WD front axle, Class 1.5 HD; TerraGlide suspended front axle optional on Electro Command Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published Dual Command: 75.7 in Wheelbase Not Published Dual Command: 89.9 in; Electro Command: 93.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Dual Command: 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Dual Command: 102.1 in; Electro Command: 107 in Overall Length Not Published Dual Command: 160.9 in; Electro Command: 165 in ▶ WeightTractor Weight (Base) Not Published Dual Command (ROPS): 7,672 lb; Dual Command (Cab): 8,157 lb; Electro Command (shipping weight, less ballast): 10,031 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published 14.9R24 R1 Agricultural - Rear Not Published 18.4R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer style or European style attachment system Loader Model 630LU; 635LU 810LA (NSL); 815LA (MSL) Loader Lift Height 143.9 in (630LU and 635LU) 825TL: 139.0 in; 835TL: 146.9 in (to pivot pin) Loader Lift Capacity (Full Height) 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, @ 31.5 in) 825TL NSL: 2,954 lb; 825TL MSL: 3,086 lb; 835TL NSL: 3,638 lb; 835TL MSL: 3,836 lb (to max height, measured 31.5 in forward of pivot pin) Loader Breakout Force Not Published 825TL NSL: 3,109 lb; 825TL MSL: 3,417 lb; 835TL NSL: 3,880 lb; 835TL MSL: 4,277 lb (measured 31.5 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
