▶ EngineEngine Manufacturer Mitsubishi Mitsubishi (MHI) Engine Model S3L2-W461GT S3L2 Engine Type 3-cylinder, naturally aspirated, liquid-cooled diesel Indirect injection, swirl chamber diesel No. of Cylinders 3 3 Displacement 80.4 in³ 80.4 in³ Rated Engine Speed 2500 rpm 2500 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power Gear: 19.2 hp; HST: 17.1 hp XG3025 (gear): 19.2 hp; XG3025H (HST): 17.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid with recirculating bypass Water-cooled Air Cleaner Dual element dry air cleaner (outer and inner element) Dry Fuel System In-line injection pump Indirect injection Alternator 50 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Mechanical Gear pump, engine driven Implement Flow 7.9 gpm 7.9 gpm Steering Flow 4.6 gpm 4.6 gpm Total Hydraulic Flow 12.5 gpm 12.5 gpm Overall Hydraulic Pump Flow 12.5 gpm 12.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None standard No. of Optional Remote Valves 1 or 2 1 or 2 optional (double-acting, 2 or 4 quick couplers) ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 7.4 gal Coolant Capacity 1.3 gal 1.3 gal Crankcase Capacity 4.4 qt 1.1 gal Transmission / Hydraulic System Capacity 8.5 gal 8.5 gal Front Axle Fluid Capacity 6.9 qt 1.7 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability HST: Standard; Gear: Optional (2,000 rpm) Optional Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Gear: 12x12 synchronized shuttle; HST: 3-range hydrostatic, dual pedal XG3025 (gear): Synchro shuttle; XG3025H (HST): HST No. of Speeds Gear: 12F/12R; HST: Infinite (3 ranges) XG3025 (gear): F12 x R12; XG3025H (HST): 3 ranges (HST) Max Travel Speed (Forward) HST: 15.3 mph; Gear: 13.8 mph Not Published Max Travel Speed (Reverse) Gear: 13.10 mph; HST: 10.79 mph Not Published Clutch Gear: 9.4 in disc; HST: Not applicable XG3025 (gear): dry single clutch; XG3025H (HST): n/a Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 117.2 in 118 in Overall Width 54.1 in 54 in Wheelbase 65.9 in 66 in Ground Clearance 13 in Not Published Min. Turn Radius without Brakes 120 in (left turn); 129.8 in (right turn) 10.5 ft Height to Top of ROPS 88.2 in 88 in Height to Top of ROPS (folded) 68.2 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Gear: 2,434 lb; HST: 2,469 lb XG3025 (gear): 2,434 lb; XG3025H (HST): 2,469 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Ag, industrial or turf tires R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.50-14 25x8.5-14 R3 Turf - Rear 41x14.00-20 41x14-20 R4 Industrial - Front 25x8.50-14 25x8.5-14 R4 Industrial - Rear 43x16-20 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System 200LC: tool-free quick-mount system; optional skid-steer quick-attach plates Not Published Loader Model 200LC LL3110 Loader Lift Height 200LC: 94.3 in LL3110: 94.3 in Loader Lift Capacity (Full Height) 200LC: 1,600 lb LL3110: 1,600 lb Loader Breakout Force 200LC: 2,637 lb LL3110: 2,637 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total Not Published
