▶ EngineEngine Manufacturer Yanmar Mitsubishi Engine Model 3TNV80F S3L2 Engine Type 3-cylinder, naturally aspirated, liquid-cooled diesel 3-cylinder diesel No. of Cylinders 3 3 Displacement 77.3 in³ 80.4 in³ Rated Engine Speed 3000 rpm 2700 rpm Engine Power (Gross) 24.7 hp 24.4 hp PTO Power 17.2 hp 18.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid with recirculating bypass Liquid-cooled Air Cleaner Single-element dry air cleaner Single replaceable dry element Fuel System In-line injection pump, indirect injection (swirl chamber) Not Published Alternator 40 A, 12 V 50 A ▶ HydraulicsPump Type Gear Not Published Implement Flow 4.6 gpm 6.7 gpm Steering Flow 2.1 gpm 2.9 gpm Total Hydraulic Flow 6.7 gpm 9.6 gpm (6.7 + 2.9, computed) Overall Hydraulic Pump Flow 6.7 gpm 9.6 gpm (6.7 + 2.9, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 1 (DIA, optional) ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity 3.49 qt Not Published Crankcase Capacity 3 qt Not Published Transmission / Hydraulic System Capacity 3.3 gal Not Published Front Axle Fluid Capacity 0.5 gal Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard (2,500 rpm) Standard, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 992 lb 1,433 lb Hitch Lift Capacity (at 24”) 728 lb 1,058 lb Lift Control Type Lift-hold-lower Chain-type stabilizers, fixed link ends ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic, dual pedal 2-range hydrostatic (HST), dual pedal No. of Speeds Infinite (2 ranges) HST, 2 ranges Max Travel Speed (Forward) 9.1 mph 11.3 mph (HST, R4 tires) Max Travel Speed (Reverse) 5.5 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical, foot-operated rear differential lock Mechanical rear differential lock (foot pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Mechanical wet multi-disc Seat Suspension & Adjustability Deluxe high-back seat with armrests and adjustable backrest Not Published Front Axle Type 4WD Four-wheel drive (standard) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 97.4 in 103.6 in Overall Width 46.7 in 48 in Wheelbase 56.1 in 59 in Ground Clearance 12 in Not Published Min. Turn Radius without Brakes 94 in Not Published Height to Top of ROPS 90 in 85.5 in Height to Top of ROPS (folded) 64 in Not Published Height to Top of Cab Model 87.4 in Not Published ▶ WeightTractor Weight (Base) ROPS: 1,444 lb; Cab: 1,805 lb 1,832 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial R3 turf tread or R4 industrial tread R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 18x8.50-10 23x8.50-12 R3 Turf - Rear 26x12.0-12 33x12-16.5 R4 Industrial - Front 18x8.50-10 23x8.50-12 R4 Industrial - Rear 26x12.0-12 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System 100LC: Quick Mount system, no tools needed Not Published Loader Model 100LC 235TL Loader Lift Height 100LC: 72 in 235TL: 80.7 in Loader Lift Capacity (Full Height) 100LC: 1,005 lb 235TL: 1,034 lb Loader Breakout Force 100LC: 2,078 lb 235TL: 1,672 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total Basic 2 years; powertrain 3 years (5 years total)
