▶ EngineEngine Manufacturer LS Mtron TYM Engine Model L3C19-T5 A1700N4-BUTR_4 Engine Type 3-cylinder, turbocharged, liquid-cooled diesel Vertical, 4-stroke, water-cooled diesel No. of Cylinders 3 3 Displacement 114.7 in³ 104.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power Gear: 29.7 hp; HST: 28 hp 29.5 hp Engine Emissions Constraints Tier 4 EPA Final Tier4 Cooling System Type Pressurized liquid with recirculating bypass Water-cooled Air Cleaner Dual element dry air cleaner (primary and inner safety element) Not Published Fuel System High pressure common rail, ECU-controlled timing Not Published Alternator 70 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Gear Not Published Implement Flow 8.2 gpm 8.2 gpm Steering Flow Gear: 4.2 gpm; HST: 5.3 gpm 4.4 gpm Total Hydraulic Flow Gear: 12.4 gpm; HST: 13.5 gpm 12.6 gpm Overall Hydraulic Pump Flow Gear: 12.4 gpm; HST: 13.5 gpm 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 or 2 Up to 2 ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 7.13 gal Coolant Capacity 7.5 qt 1.32 gal Crankcase Capacity 5.8 qt 1.14 gal Transmission / Hydraulic System Capacity 8.5 gal 9.77 gal Front Axle Fluid Capacity 6.9 qt 1.69 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent PTO Rear 540 rpm Not Published Mid-PTO Availability HST: Standard; Gear: Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 3,307 lb Hitch Lift Capacity (at 24”) 1,433 lb 2,425 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Gear: 12x12 synchronized shuttle; HST: 3-range hydrostatic, dual pedal Hydrostatic (HST), 3-range No. of Speeds Gear: 12F/12R; HST: Infinite (3 ranges) 3 range (HST) Max Travel Speed (Forward) Gear: 14.2 mph; HST: 14.8 mph 19.08 mph Max Travel Speed (Reverse) Gear: 13.63 mph; HST: 14.96 mph 19.08 mph Clutch Gear: 9.4 in single dry disc; HST: Not applicable None (HST) Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Mechanical suspension seat, fore/aft adjustable, tilting Not Published Front Axle Type 4WD Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121 in 134.88 in Overall Width 66.5 in 56.7 in Wheelbase 67.5 in 65.7 in Ground Clearance 13 in Not Published Min. Turn Radius without Brakes 123 in (left turn); 124 in (right turn) Not Published Height to Top of ROPS 87.7 in 96.85 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,067 lb 3,164 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 ag 8.0-16 / 12.4-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20 R1 Agricultural - Front 7-14 8.0-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front 25x8.50-14 Not Published R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 25x8.50-14 28x8.50-15 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System 140TL: tool-free quick-mount system; optional skid-steer quick-attach plates SSQA Loader Model 140TL BBL400 Loader Lift Height 140TL: 91.5 in 104 in Loader Lift Capacity (Full Height) 140TL: 1,500 lb 2,200 lb (at pivot pin) Loader Breakout Force 140TL: 2,700 lb 3,660 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
