▶ EngineEngine Manufacturer LS Mtron TYM Engine Model L3C19-T5 T1700N6 Engine Type 3-cylinder, turbocharged, liquid-cooled diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 114.7 in³ 104.5 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 35 hp 35 hp PTO Power Gear: 29.7 hp; HST: 28 hp 30 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid with recirculating bypass Not Published Air Cleaner Dual element dry air cleaner (primary and inner safety element) Dry element Fuel System High pressure common rail, ECU-controlled timing IDI (indirect injection) Alternator 70 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Gear Dual gear pump Implement Flow 8.2 gpm 7.5 gpm Steering Flow Gear: 4.2 gpm; HST: 5.3 gpm 4.0 gpm Total Hydraulic Flow Gear: 12.4 gpm; HST: 13.5 gpm 11.5 gpm Overall Hydraulic Pump Flow Gear: 12.4 gpm; HST: 13.5 gpm 11.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Loader: 4 / Rear: 0 No. of Optional Remote Valves 1 or 2 Up to 4 ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 8.7 gal Coolant Capacity 7.5 qt 5.3 qt Crankcase Capacity 5.8 qt 4.5 qt Transmission / Hydraulic System Capacity 8.5 gal T3035R: 8.9 gal; T3035H: 9.8 gal Front Axle Fluid Capacity 6.9 qt 6.8 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability HST: Standard; Gear: Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 3,307 lb Hitch Lift Capacity (at 24”) 1,433 lb 2,425 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Gear: 12x12 synchronized shuttle; HST: 3-range hydrostatic, dual pedal T3035R: Synchromesh; T3035H: HST No. of Speeds Gear: 12F/12R; HST: Infinite (3 ranges) T3035R: F12 x R12; T3035H: 3-Range Max Travel Speed (Forward) Gear: 14.2 mph; HST: 14.8 mph T3035R: 14.4 mph; T3035H: 18.8 mph Max Travel Speed (Reverse) Gear: 13.63 mph; HST: 14.96 mph Not Published Clutch Gear: 9.4 in single dry disc; HST: Not applicable T3035R: Dry single plate; T3035H: None (HST) Differential Lock & Limited Slip Options Mechanical rear differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Mechanical suspension seat, fore/aft adjustable, tilting Suspension seat Front Axle Type 4WD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121 in 120.9 in Overall Width 66.5 in 56.3 in Wheelbase 67.5 in 65.7 in Ground Clearance 13 in 14.4 in Min. Turn Radius without Brakes 123 in (left turn); 124 in (right turn) 105.5 in Height to Top of ROPS 87.7 in 97.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,067 lb 2,970 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 / 41x14.00; R4 Industrial 10-16.5 / 420/70-24 R1 Agricultural - Front 7-14 8-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front 25x8.50-14 27x8.5-15 R3 Turf - Rear 41x14.00-20 41x14.00 R4 Industrial - Front 25x8.50-14 10-16.5 R4 Industrial - Rear 43x16-20 420/70-24 ▶ Loader & AttachmentsQuick Attach Loader System 140TL: tool-free quick-mount system; optional skid-steer quick-attach plates Not Published Loader Model 140TL L3035 Loader Lift Height 140TL: 91.5 in L3035: 104.9 in Loader Lift Capacity (Full Height) 140TL: 1,500 lb L3035: 2,200 lb Loader Breakout Force 140TL: 2,700 lb L3035: 3,422 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months
