▶ EngineEngine Manufacturer LS Mtron LS Engine Model L3C19-T4 L3C19-T Engine Type 3-cylinder, turbocharged, liquid-cooled diesel 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power Gear: 34 hp; HST: 32 hp 34 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid with recirculating bypass Liquid-cooled Air Cleaner Dual element dry air cleaner (primary and inner safety element) Dry Fuel System High pressure common rail, ECU-controlled timing CRDI (Delphi common rail direct injection) Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear Gear pump, engine driven Implement Flow 8.2 gpm 8.2 gpm Steering Flow Gear: 4.2 gpm; HST: 5.3 gpm 5.5 gpm Total Hydraulic Flow Gear: 12.4 gpm; HST: 13.5 gpm 13.7 gpm Overall Hydraulic Pump Flow Gear: 12.4 gpm; HST: 13.5 gpm 13.7 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves 1 or 2 1 or 2 pairs (optional) ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 7.4 gal Coolant Capacity 7.5 qt 1.9 gal Crankcase Capacity 5.8 qt 1.5 gal Transmission / Hydraulic System Capacity 8.5 gal 8.5 gal Front Axle Fluid Capacity 6.9 qt 1.7 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent (wet disc clutch) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability HST: Standard; Gear: Optional (2,000 rpm) Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Gear: 12x12 synchronized shuttle; HST: 3-range hydrostatic, dual pedal Synchro Shuttle No. of Speeds Gear: 12F/12R; HST: Infinite (3 ranges) F12 x R12 Max Travel Speed (Forward) Gear: 14.2 mph; HST: 14.8 mph 14.33 mph Max Travel Speed (Reverse) Gear: 13.63 mph; HST: 14.96 mph 13.63 mph Clutch Gear: 9.4 in single dry disc; HST: Not applicable Dry single clutch Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Mechanical suspension seat, fore/aft adjustable, tilting Not Published Front Axle Type 4WD Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121 in 121 in Overall Width 66.5 in 54 in (R1); 66 in (R4) Wheelbase 67.5 in 69 in Ground Clearance 13 in Not Published Min. Turn Radius without Brakes 123 in (left turn); 124 in (right turn) 10.79 ft (left); 11.02 ft (right) Height to Top of ROPS 87.7 in 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,067 lb 2,881 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 agricultural, R4 industrial or R3 turf at no extra cost R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.50-14 25x8.50-14 R3 Turf - Rear 41x14.00-20 41x14-20 R4 Industrial - Front 25x8.50-14 27x8.50-14 R4 Industrial - Rear 43x16-20 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System 140TL: tool-free quick-mount system; optional skid-steer quick-attach plates Not Published Loader Model 140TL LL3302 Loader Lift Height 140TL: 91.5 in LL3302: 94 in Loader Lift Capacity (Full Height) 140TL: 1,500 lb LL3302: 2,153 lb (at pivot pin, full height) Loader Breakout Force 140TL: 2,700 lb LL3302: 3,579 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total 6-year limited warranty
