▶ EngineEngine Manufacturer FPT Mitsubishi Engine Model R753 K39 Engine Type Turbocharged, intercooled 3-cylinder diesel 4-cylinder turbocharged and intercooled diesel No. of Cylinders 3 4 Displacement 136 in³ 134.7 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 53 hp 53.6 hp PTO Power 45 hp Gear: 42.1 hp; HST: 40.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid with recirculating bypass Liquid-cooled Air Cleaner 2-stage Not Published Fuel System Common rail direct injection (CRDI) Common-rail, direct injection, electronic engine management Alternator 75 A Not Published ▶ HydraulicsPump Type Two engine-driven gear pumps, open center, fixed displacement Engine-driven gear-type pump Implement Flow 12 gpm 11.6 gpm Steering Flow 5.5 gpm 6.8 gpm Total Hydraulic Flow 17.5 gpm Not Published Overall Hydraulic Pump Flow 17.5 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.6 gpm No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 14.5 gal Coolant Capacity 10.6 qt Not Published Crankcase Capacity 6.7 qt Not Published Transmission / Hydraulic System Capacity ROPS 2WD: 6.1 gal; ROPS 4WD: 6.6 gal Not Published Front Axle Fluid Capacity 4WD: 8.0 qt Not Published ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulically engaged PTO Rear 540 rpm (540/540E optional) 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category II/I Category I Hitch Lift Capacity 3,307 lb Not Published Hitch Lift Capacity (at 24”) 2,701 lb 3,086 lb Lift Control Type Position control with mechanical draft control Position control; draft control optional ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized shuttle 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST No. of Speeds 8F/8R Power shuttle: 12F / 12R; Servo-HST: 3-range infinite Max Travel Speed (Forward) 19.1 mph (13.6x28 rear tires); 19.8 mph (14.9x28 rear tires) Not Published Max Travel Speed (Reverse) 20.2 mph (13.6x28 rear tires); 20.9 mph (14.9x28 rear tires) Not Published Clutch Dry, 11 in organic plate (LUK) Wet multi-disc (power shuttle) Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock Mechanical rear differential lock, right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Drop-axle rear with bull gear final drives Steering Power steering Power steering, tilt steering wheel Brakes Individual mechanically actuated wet disc Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability Deluxe contoured suspension seat, adjusts to operator height Suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Front Axle Type 4WD: limited-slip front axle with front differential lock, mechanical engagement Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch ROPS 2WD: 129.5 in; ROPS 4WD: 134.0 in 132.3 in Overall Width ROPS 2WD: 66.5 in; ROPS 4WD: 67.5 in 65.4 in Wheelbase ROPS 2WD: 77.6 in; ROPS 4WD: 77.2 in 77.2 in Ground Clearance ROPS 2WD: 19.5 in; ROPS 4WD: 15.9 in Not Published Min. Turn Radius without Brakes ROPS 2WD: 122.0 in; ROPS 4WD: 190.9 in Not Published Height to Top of ROPS ROPS 2WD: 96.5 in; ROPS 4WD: 97.6 in Not Published Height to Top of ROPS (folded) ROPS 2WD: 75.9 in; ROPS 4WD: 77.0 in Not Published Height to Top of Cab Model Not Published 92.9 in ▶ WeightTractor Weight (Base) ROPS 2WD: 4,442 lb; ROPS 4WD: 5,059 lb ROPS: 4,145 lb; Cab: 4,575 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf, R4 industrial Ag: 9.5x16 front, 13.6x28 rear (16.9x24 optional); turf: 27x10.50-15 front, 44x18.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/80R16 front, 360/80R28 rear) R1 Agricultural - Front ROPS 2WD: 7.5x16, 6 ply; ROPS 4WD: 8.3x24, 6 ply 9.5-16 R1 Agricultural - Rear 13.6x28 R1, 6 ply 13.6-28 (16.9-24 optional) R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front 12.5x18 10-16.5 or 250/80R16 R4 Industrial - Rear 18.4x24 R4 17.5L-24 or 360/80R28 ▶ Loader & AttachmentsQuick Attach Loader System 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) DL135: universal skid steer or compact quick-attach tool carrier Loader Model 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) DL135 Loader Lift Height 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in DL135: 110.2 in Loader Lift Capacity (Full Height) 616TL: 1,940 lb; 621TL: 3,549 lb; 626TL: 2,447 lb (at the pivot pin, full height) DL135: 2,420 lb Loader Breakout Force 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in ahead of pivot pin) DL135: 2,860 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
