▶ EngineEngine Manufacturer FPT LS Mtron Engine Model R753 L3CRV-T8 Engine Type Turbocharged, intercooled 3-cylinder diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 136 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 53 hp 50 hp PTO Power 45 hp Gear: 42.5 hp; HST: 40 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid with recirculating bypass Liquid cooled Air Cleaner 2-stage Replaceable primary and inner elements Fuel System Common rail direct injection (CRDI) Electronically controlled common rail direct injection Alternator 75 A ROPS: 70 A, 12 V; Cab: 85 A, 12 V ▶ HydraulicsPump Type Two engine-driven gear pumps, open center, fixed displacement Gear Implement Flow 12 gpm 8.2 gpm Steering Flow 5.5 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 17.5 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 17.5 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 17.2 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity 10.6 qt 2.3 gal Crankcase Capacity 6.7 qt 5.8 qt Transmission / Hydraulic System Capacity ROPS 2WD: 6.1 gal; ROPS 4WD: 6.6 gal 11.4 gal Front Axle Fluid Capacity 4WD: 8.0 qt 2.2 gal ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm (540/540E optional) 540 rpm Mid-PTO Availability Not Published Standard (2000 rpm) Category, 3-Point Hitch Category II/I Category I Hitch Lift Capacity 3,307 lb 2,756 lb Hitch Lift Capacity (at 24”) 2,701 lb 2,116 lb Lift Control Type Position control with mechanical draft control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized shuttle Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 8F/8R Gear: 16F/16R; HST: 3-range Max Travel Speed (Forward) 19.1 mph (13.6x28 rear tires); 19.8 mph (14.9x28 rear tires) Gear: 17.0 mph; HST: 17.9 mph Max Travel Speed (Reverse) 20.2 mph (13.6x28 rear tires); 20.9 mph (14.9x28 rear tires) Gear: 15.3 mph; HST: 11.37 mph Clutch Dry, 11 in organic plate (LUK) Gear: dry single disc (10.8 in); HST: n/a Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Individual mechanically actuated wet disc Wet multi-disc Seat Suspension & Adjustability Deluxe contoured suspension seat, adjusts to operator height ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Front Axle Type 4WD: limited-slip front axle with front differential lock, mechanical engagement Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch ROPS 2WD: 129.5 in; ROPS 4WD: 134.0 in 128.1 in Overall Width ROPS 2WD: 66.5 in; ROPS 4WD: 67.5 in 69.1 in Wheelbase ROPS 2WD: 77.6 in; ROPS 4WD: 77.2 in 73.2 in Ground Clearance ROPS 2WD: 19.5 in; ROPS 4WD: 15.9 in 15 in Min. Turn Radius without Brakes ROPS 2WD: 122.0 in; ROPS 4WD: 190.9 in 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Height to Top of ROPS ROPS 2WD: 96.5 in; ROPS 4WD: 97.6 in 97.1 in Height to Top of ROPS (folded) ROPS 2WD: 75.9 in; ROPS 4WD: 77.0 in Not Published Height to Top of Cab Model Not Published 94 in ▶ WeightTractor Weight (Base) ROPS 2WD: 4,442 lb; ROPS 4WD: 5,059 lb ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf, R4 industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front ROPS 2WD: 7.5x16, 6 ply; ROPS 4WD: 8.3x24, 6 ply 9.5-16 R1 Agricultural - Rear 13.6x28 R1, 6 ply 13.6-24 R3 Turf - Front Not Published 28x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front 12.5x18 12x16.5 R4 Industrial - Rear 18.4x24 R4 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) Tool-free loader mount; optional skid-steer quick-attach plates Loader Model 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) 260TLA Loader Lift Height 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in 260TLA: 109 in Loader Lift Capacity (Full Height) 616TL: 1,940 lb; 621TL: 3,549 lb; 626TL: 2,447 lb (at the pivot pin, full height) 260TLA: 2,371 lb Loader Breakout Force 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in ahead of pivot pin) 260TLA: 4,081 lb ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
