▶ EngineEngine Manufacturer FPT Kubota Engine Model S8000 F2803 Engine Type Turbocharged 3-cylinder diesel Diesel, 5-cylinder, liquid-cooled No. of Cylinders 3 5 Displacement 179 in³ 167.6 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 54 hp 54 hp PTO Power 40 hp 45 hp Engine Emissions Constraints Tier 4B Not Published Cooling System Type Not Published Liquid-cooled Air Cleaner PowerCore dry air cleaner Dual dry elements Fuel System Bosch electronic high-pressure common rail Not Published Alternator 120 A Not Published ▶ HydraulicsPump Type Dual gear pumps Not Published Implement Flow 12.6 gpm Not Published Steering Flow 7.6 gpm Not Published Total Hydraulic Flow 20.2 gpm 17.1 gpm Overall Hydraulic Pump Flow 20.2 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 21.7 gal ROPS: 17.2 gal; Cab: 25.1 gal Coolant Capacity Not Published 7.7 qt Crankcase Capacity Not Published 8.5 qt Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully independent, hydraulic wet clutch Live PTO Rear 540 rpm (540/540E optional) 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category II/I Hitch Lift Capacity Not Published 4,200 lb Hitch Lift Capacity (at 24”) 3,500 lb 3,307 lb Lift Control Type Mechanical draft control with upper-link draft sensing; Lift-O-Matic rear hitch control Position, draft and mix control ▶ Transmission & DrivetrainTransmission Type 12x12 hydraulic power shuttle Synchronized shuttle, 8F/8R (12F/12R with creeper) No. of Speeds 12F/12R 8F/8R (12F/12R with creeper) Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch 11 in single dry disc Not Published Differential Lock & Limited Slip Options Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic-assist wet brakes Mechanical wet disc Seat Suspension & Adjustability Cloth air-suspension seat with fold-back instructor seat Not Published Front Axle Type 4WD (MFD) limited-slip front axle, electro-hydraulic engagement Not Published Front Axle Rating 6,500 lb dynamic capacity Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 67.2 in (minimum) Wheelbase 83.6 in ROPS: 78.7 in; Cab: 81.7 in Ground Clearance Not Published 16.9 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 93.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in 98.1 in Overall Length 154.1 in n/a Overall Length with 3-Point Hitch n/a 2WD ROPS: 137.6 in; 4WD ROPS: 134.1 in; 2WD cab: 140.6 in; 4WD cab: 137.1 in ▶ WeightTractor Weight (Base) Not Published 2WD ROPS: 3,748 lb; 4WD ROPS: 3,968 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) Standard: 6.5-16 front (2WD), 9.5-22 front (4WD), 14.9-28 rear R1 Agricultural - Front 11.2x24 R1, 6 ply 8.3-24 R1 Agricultural - Rear 16.9x30 R1, 6 ply 14.9-28 R3 Turf - Front Not Published 2WD: 9.00-10; 4WD: 29x12.5-15 R3 Turf - Rear Not Published 21.5L-16.1 R3 R4 Industrial - Front 12.5/80-18 R4, 10 ply 12.5/80-18 R4 R4 Industrial - Rear 19.5L-24 R4, 10 ply 16.9-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System 72 in bucket with SSL (skid steer) or Euro-style quick attach Not Published Loader Model 550LU (non self-leveling); 555LU (mechanical self-leveling) LA1002 Loader Lift Height 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) LA1002: 115.6 in Loader Lift Capacity (Full Height) Not Published LA1002: 2,579 lb Loader Breakout Force Not Published LA1002: 3,330 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
