▶ EngineEngine Manufacturer FPT Iseki Engine Model S8000 E4FH Engine Type Turbocharged 3-cylinder diesel 4-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 4 Displacement 179 in³ 148.6 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 54 hp 53.6 hp PTO Power 40 hp 40 hp Engine Emissions Constraints Tier 4B Tier 4 Cooling System Type Not Published Liquid cooled Air Cleaner PowerCore dry air cleaner Dry Fuel System Bosch electronic high-pressure common rail Common rail direct injection Alternator 120 A Not Published ▶ HydraulicsPump Type Dual gear pumps Two gear-type pumps for steering and 3-point/remotes Implement Flow 12.6 gpm 12.6 gpm Steering Flow 7.6 gpm 7 gpm Total Hydraulic Flow 20.2 gpm 19.6 gpm (12.6 + 7, computed) Overall Hydraulic Pump Flow 20.2 gpm 19.6 gpm (12.6 + 7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 21.7 gal 14.0 gal Coolant Capacity Not Published 7.61 qt Crankcase Capacity Not Published 7.82 qt Transmission / Hydraulic System Capacity Not Published 10.04 gal Front Axle Fluid Capacity Not Published 9 qt ▶ PTO & HitchPTO Type Fully independent, hydraulic wet clutch Independent with SoftStart electronic modulation PTO Rear 540 rpm (540/540E optional) 540 rpm (1-3/8 in) Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch Category I/II Category I and II Hitch Lift Capacity Not Published 3,483 lb Hitch Lift Capacity (at 24”) 3,500 lb 3,086 lb Lift Control Type Mechanical draft control with upper-link draft sensing; Lift-O-Matic rear hitch control Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 hydraulic power shuttle 12x12 power shuttle No. of Speeds 12F/12R 12 forward and 12 reverse Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch 11 in single dry disc Not Published Differential Lock & Limited Slip Options Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic-assist wet brakes Wet disc Seat Suspension & Adjustability Cloth air-suspension seat with fold-back instructor seat Open station: vinyl-clad seat; standard cab: spring-suspension seat with armrests; upgraded cab: air-suspension seat with armrests Front Axle Type 4WD (MFD) limited-slip front axle, electro-hydraulic engagement Solid cast front axle Front Axle Rating 6,500 lb dynamic capacity Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 70.1 in Wheelbase 83.6 in Not Published Ground Clearance Not Published 14.0 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 102.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in 92.9 in Overall Length 154.1 in n/a Overall Length with 3-Point Hitch n/a 132.3 in ▶ WeightTractor Weight (Base) Not Published ROPS: 4,035 lb; Cab: 4,420 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 11.2x24 R1, 6 ply 9.5-16 R1 Agricultural - Rear 16.9x30 R1, 6 ply 13.6-28 standard; 16.9-24 optional R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front 12.5/80-18 R4, 10 ply 10-16.5 R4 Industrial - Rear 19.5L-24 R4, 10 ply 14.9-24; 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System 72 in bucket with SSL (skid steer) or Euro-style quick attach FL2814: pin-type or skid steer Loader Model 550LU (non self-leveling); 555LU (mechanical self-leveling) FL2814 Loader Lift Height 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) FL2814: 111 in Loader Lift Capacity (Full Height) Not Published FL2814: 2,570 lb Loader Breakout Force Not Published FL2814: 3,910 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
