▶ EngineEngine Manufacturer FPT Kubota Engine Model R753 V2403-CR-TIE5 Engine Type Turbocharged, intercooled 3-cylinder diesel Turbocharged and intercooled, common-rail, liquid-cooled diesel No. of Cylinders 3 4 Displacement 136 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 60 hp 60 hp PTO Power 51 hp 53 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Pressurized liquid with recirculating bypass Water-cooled Air Cleaner 2-stage Not Published Fuel System Common rail direct injection (CRDI) Common rail direct injection Alternator 75 A Not Published ▶ HydraulicsPump Type Two engine-driven gear pumps, open center, fixed displacement Not Published Implement Flow 12 gpm 9.83 gpm Steering Flow 5.5 gpm Not Published Total Hydraulic Flow 17.5 gpm Not Published Overall Hydraulic Pump Flow 17.5 gpm Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves 2 Up to 3 (optional) ▶ Fluid CapacityFuel Tank Capacity 17.2 gal Not Published Coolant Capacity 10.6 qt Not Published Crankcase Capacity 6.7 qt Not Published Transmission / Hydraulic System Capacity ROPS 2WD: 6.1 gal; ROPS 4WD: 6.6 gal Not Published Front Axle Fluid Capacity 4WD: 8.0 qt Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (540/540E optional) 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category I and II Hitch Lift Capacity 3,307 lb 3,858 lb Hitch Lift Capacity (at 24”) 2,701 lb 2,976 lb Lift Control Type Position control with mechanical draft control Not Published ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized shuttle Hydrostatic transmission, 3-range, with Hydro-Dual Speed (H-DS) No. of Speeds 8F/8R 3-range Max Travel Speed (Forward) 19.1 mph (13.6x28 rear tires); 19.8 mph (14.9x28 rear tires) 18.5 mph Max Travel Speed (Reverse) 20.2 mph (13.6x28 rear tires); 20.9 mph (14.9x28 rear tires) Not Published Clutch Dry, 11 in organic plate (LUK) Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Open ROPS or enclosed cab Steering Power steering Hydrostatic power steering Brakes Individual mechanically actuated wet disc Wet disc type Seat Suspension & Adjustability Deluxe contoured suspension seat, adjusts to operator height Not Published Front Axle Type 4WD: limited-slip front axle with front differential lock, mechanical engagement Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch ROPS 2WD: 129.5 in; ROPS 4WD: 134.0 in 133.9 in (without 3-point hitch) Overall Width ROPS 2WD: 66.5 in; ROPS 4WD: 67.5 in 67.3 in Wheelbase ROPS 2WD: 77.6 in; ROPS 4WD: 77.2 in 81.3 in Ground Clearance ROPS 2WD: 19.5 in; ROPS 4WD: 15.9 in 15.4 in Min. Turn Radius without Brakes ROPS 2WD: 122.0 in; ROPS 4WD: 190.9 in 9.5 ft (with brake applied) Height to Top of ROPS ROPS 2WD: 96.5 in; ROPS 4WD: 97.6 in 98.0 in Height to Top of ROPS (folded) ROPS 2WD: 75.9 in; ROPS 4WD: 77.0 in Not Published Height to Top of Cab Model Not Published 93.3 in ▶ WeightTractor Weight (Base) ROPS 2WD: 4,442 lb; ROPS 4WD: 5,059 lb 4,387 lb (ROPS); 4,762 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf, R4 industrial Standard: 9.5-16 front, 14.9-26 rear R1 Agricultural - Front Not Published 9.5-16 R1 Agricultural - Rear 14.9x28 R1, 6 ply 14.9-26 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5x18 Not Published R4 Industrial - Rear 18.4x24 R4 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) LA1056, LM1056: toolless loader removal with integrated parking stands; optional third-function valve Loader Model 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) LA1056; LM1056 Loader Lift Height 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in LA1056: 117 in; LM1056: 117 in Loader Lift Capacity (Full Height) 616TL: 1,940 lb; 621TL: 3,549 lb; 626TL: 2,447 lb (at the pivot pin, full height) LA1056: 2,427 lb; LM1056: 2,471 lb Loader Breakout Force 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in ahead of pivot pin) LA1056: 4,069 lbf; LM1056: 4,061 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
