▶ EngineEngine Manufacturer FPT FPT Industrial Engine Model S8000 F5C Engine Type Turbocharged 3-cylinder diesel 4-cylinder diesel, turbocharged No. of Cylinders 3 4 Displacement 179 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 64 hp 74 hp PTO Power 50 hp 65 hp Engine Emissions Constraints Tier 4B Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner PowerCore dry air cleaner Dry Fuel System Bosch electronic high-pressure common rail Common rail fuel injection Alternator 120 A 120 A ▶ HydraulicsPump Type Dual gear pumps Open center, dual pumps: implement pump plus dedicated steering and services pump Implement Flow 12.6 gpm 12.5 gpm Steering Flow 7.6 gpm 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) Total Hydraulic Flow 20.2 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Overall Hydraulic Pump Flow 20.2 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves 1 Up to 3 rear remotes ▶ Fluid CapacityFuel Tank Capacity 21.7 gal 23.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully independent, hydraulic wet clutch Fully independent PTO Rear 540 rpm (540/540E optional) 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category II / I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,500 lb 3,664 lb Lift Control Type Mechanical draft control with upper-link draft sensing; Lift-O-Matic rear hitch control Mechanical draft control; top link draft sensing ▶ Transmission & DrivetrainTransmission Type 12x12 hydraulic power shuttle 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions No. of Speeds 12F/12R 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) Max Travel Speed (Forward) 25 mph 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) Max Travel Speed (Reverse) Not Published 20.1 mph Clutch 11 in single dry disc Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Differential Lock & Limited Slip Options Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic-assist wet brakes Hydraulic wet disc Seat Suspension & Adjustability Cloth air-suspension seat with fold-back instructor seat Air-suspension seat with integrated armrest and 10° swivel (optional, cab); full-size instructor seat with seat belt (cab) Front Axle Type 4WD (MFD) limited-slip front axle, electro-hydraulic engagement Heavy-duty 2WD front axle; electronic 4WD front axle (optional on T4.75, standard on T4.65) Front Axle Rating 6,500 lb dynamic capacity Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published Not Published Wheelbase 83.6 in 85.8 in (2WD); 83.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 134 in (2WD front axle) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published 76 to 78.9 in Height to Top of Cab Model 100.2 in 94.8 to 97.8 in Overall Length 154.1 in 151 in ▶ WeightTractor Weight (Base) Not Published 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) Not Published R1 Agricultural - Front 11.2x24 R1, 6 ply Not Published R1 Agricultural - Rear 16.9x30 R1, 6 ply Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 R4, 10 ply Not Published R4 Industrial - Rear 19.5L-24 R4, 10 ply Not Published ▶ Loader & AttachmentsQuick Attach Loader System 72 in bucket with SSL (skid steer) or Euro-style quick attach Skid-steer-style or Euro-style quick attach faceplate Loader Model 550LU (non self-leveling); 555LU (mechanical self-leveling) Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) Loader Lift Height 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in Loader Lift Capacity (Full Height) Not Published 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (at max height, 31.5 in forward of the bucket pivot point) Loader Breakout Force Not Published 655TL NSL: 3,739 lb; 622TL: 3,042 lb; 627TL: 3,307 lb (at 31.5 in forward of the bucket pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
