▶ EngineEngine Manufacturer FPT Mahindra Engine Model R753 Not Published Engine Type Turbocharged, intercooled 3-cylinder diesel Turbocharged and intercooled, direct injection diesel No. of Cylinders 3 3 Displacement 136 in³ 161.5 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 70 hp 70 hp PTO Power 62 hp 61 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid with recirculating bypass Liquid-cooled Air Cleaner 2-stage Not Published Fuel System Common rail direct injection (CRDI) Turbocharged and intercooled, direct injection, common-rail Alternator 75 A 55 A, 12 V ▶ HydraulicsPump Type Two engine-driven gear pumps, open center, fixed displacement Not Published Implement Flow 12 gpm 11.2 gpm Steering Flow 5.5 gpm 4.6 gpm Total Hydraulic Flow 17.5 gpm 15.8 gpm (11.2 + 4.6, computed) Overall Hydraulic Pump Flow 17.5 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 17.1 gal Coolant Capacity 10.6 qt Not Published Crankcase Capacity 6.7 qt Not Published Transmission / Hydraulic System Capacity ROPS 2WD: 6.1 gal; ROPS 4WD: 6.6 gal Not Published Front Axle Fluid Capacity 4WD: 8.0 qt Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (540/540E optional) 540 rpm @ 2059 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I CAT I and II with telescopic stabilizers Hitch Lift Capacity 3,307 lb 3,968 lb Hitch Lift Capacity (at 24”) 2,701 lb Not Published Lift Control Type Position control with mechanical draft control Position and draft control ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized shuttle Constant mesh with forward/reverse synchro shuttle No. of Speeds 8F/8R 8F/8R Max Travel Speed (Forward) 19.1 mph (13.6x28 rear tires); 19.8 mph (14.9x28 rear tires) Not Published Max Travel Speed (Reverse) 20.2 mph (13.6x28 rear tires); 20.9 mph (14.9x28 rear tires) Not Published Clutch Dry, 11 in organic plate (LUK) Dual dry with cerametallic lining Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Individual mechanically actuated wet disc Wet disc Seat Suspension & Adjustability Deluxe contoured suspension seat, adjusts to operator height Not Published Front Axle Type 4WD: limited-slip front axle with front differential lock, mechanical engagement Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch ROPS 2WD: 129.5 in; ROPS 4WD: 134.0 in 138.3 in (5570 2WD); 145 in (5570 4WD) Overall Width ROPS 2WD: 66.5 in; ROPS 4WD: 67.5 in 77.3 in (5570 2WD); 81 in (5570 4WD) Wheelbase ROPS 2WD: 77.6 in; ROPS 4WD: 77.2 in Not Published Ground Clearance ROPS 2WD: 19.5 in; ROPS 4WD: 15.9 in Not Published Min. Turn Radius without Brakes ROPS 2WD: 122.0 in; ROPS 4WD: 190.9 in 14 ft (5570 2WD); 15.7 ft (5570 4WD) Height to Top of ROPS ROPS 2WD: 96.5 in; ROPS 4WD: 97.6 in 103.3 in (5570 2WD); 99.7 in (5570 4WD) Height to Top of ROPS (folded) ROPS 2WD: 75.9 in; ROPS 4WD: 77.0 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) ROPS 2WD: 4,442 lb; ROPS 4WD: 5,059 lb 5,557 lb (5570 2WD); 6,302 lb (5570 4WD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf, R4 industrial Ag (5570 2WD); Ag, Industrial (5570 4WD) R1 Agricultural - Front Not Published 9.5Lx15 (5570 2WD); 11.2x24 (5570 4WD) R1 Agricultural - Rear 14.9x28 R1, 6 ply 16.9x28 (5570 2WD); 16.9x30 (5570 4WD) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5x18 12.5/80x18 (5570 4WD) R4 Industrial - Rear 18.4x24 R4 16.9x24 (5570 4WD) ▶ Loader & AttachmentsQuick Attach Loader System 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) Not Published Loader Model 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) 5565-2L (5570 2WD); 5565-4L (5570 4WD) Loader Lift Height 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in 5565-2L: 123 in; 5565-4L: 128 in Loader Lift Capacity (Full Height) 616TL: 1,940 lb; 621TL: 3,549 lb; 626TL: 2,447 lb (at the pivot pin, full height) 5565-2L: 3,250 lb; 5565-4L: 3,000 lb Loader Breakout Force 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in ahead of pivot pin) 5565-2L: 5,300 lb; 5565-4L: 4,825 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
