▶ EngineEngine Manufacturer FPT FPT Industrial Engine Model R753 F5C Engine Type Turbocharged, intercooled 3-cylinder diesel 4-cylinder diesel, turbocharged No. of Cylinders 3 4 Displacement 136 in³ 207 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 70 hp 74 hp PTO Power 62 hp 65 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid with recirculating bypass Liquid-cooled Air Cleaner 2-stage Dry Fuel System Common rail direct injection (CRDI) Common rail fuel injection Alternator 75 A 120 A ▶ HydraulicsPump Type Two engine-driven gear pumps, open center, fixed displacement Open center, dual pumps: implement pump plus dedicated steering and services pump Implement Flow 12 gpm 12.5 gpm Steering Flow 5.5 gpm 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) Total Hydraulic Flow 17.5 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Overall Hydraulic Pump Flow 17.5 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves 2 Up to 3 rear remotes ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 23.8 gal Coolant Capacity 10.6 qt Not Published Crankcase Capacity 6.7 qt Not Published Transmission / Hydraulic System Capacity ROPS 2WD: 6.1 gal; ROPS 4WD: 6.6 gal Not Published Front Axle Fluid Capacity 4WD: 8.0 qt Not Published ▶ PTO & HitchPTO Type Independent Fully independent PTO Rear 540 rpm (540/540E optional) 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category II / I Hitch Lift Capacity 3,307 lb Not Published Hitch Lift Capacity (at 24”) 2,701 lb 3,664 lb Lift Control Type Position control with mechanical draft control Mechanical draft control; top link draft sensing ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized shuttle 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions No. of Speeds 8F/8R 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) Max Travel Speed (Forward) 19.1 mph (13.6x28 rear tires); 19.8 mph (14.9x28 rear tires) 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) Max Travel Speed (Reverse) 20.2 mph (13.6x28 rear tires); 20.9 mph (14.9x28 rear tires) 20.1 mph Clutch Dry, 11 in organic plate (LUK) Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Individual mechanically actuated wet disc Hydraulic wet disc Seat Suspension & Adjustability Deluxe contoured suspension seat, adjusts to operator height Air-suspension seat with integrated armrest and 10° swivel (optional, cab); full-size instructor seat with seat belt (cab) Front Axle Type 4WD: limited-slip front axle with front differential lock, mechanical engagement Heavy-duty 2WD front axle; electronic 4WD front axle (optional on T4.75, standard on T4.65) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch ROPS 2WD: 129.5 in; ROPS 4WD: 134.0 in 151 in Overall Width ROPS 2WD: 66.5 in; ROPS 4WD: 67.5 in Not Published Wheelbase ROPS 2WD: 77.6 in; ROPS 4WD: 77.2 in 85.8 in (2WD); 83.9 in (4WD) Ground Clearance ROPS 2WD: 19.5 in; ROPS 4WD: 15.9 in Not Published Min. Turn Radius without Brakes ROPS 2WD: 122.0 in; ROPS 4WD: 190.9 in 134 in (2WD front axle) Height to Top of ROPS ROPS 2WD: 96.5 in; ROPS 4WD: 97.6 in Not Published Height to Top of ROPS (folded) ROPS 2WD: 75.9 in; ROPS 4WD: 77.0 in 76 to 78.9 in Height to Top of Cab Model Not Published 94.8 to 97.8 in ▶ WeightTractor Weight (Base) ROPS 2WD: 4,442 lb; ROPS 4WD: 5,059 lb 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf, R4 industrial Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear 14.9x28 R1, 6 ply Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5x18 Not Published R4 Industrial - Rear 18.4x24 R4 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) Skid-steer-style or Euro-style quick attach faceplate Loader Model 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) Loader Lift Height 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in Loader Lift Capacity (Full Height) 616TL: 1,940 lb; 621TL: 3,549 lb; 626TL: 2,447 lb (at the pivot pin, full height) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (at max height, 31.5 in forward of the bucket pivot point) Loader Breakout Force 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in ahead of pivot pin) 655TL NSL: 3,739 lb; 622TL: 3,042 lb; 627TL: 3,307 lb (at 31.5 in forward of the bucket pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
