▶ EngineEngine Manufacturer FPT Deutz Engine Model R753 TCD 2.9 Engine Type Turbocharged, intercooled 3-cylinder diesel 4-cylinder, turbocharged diesel No. of Cylinders 3 4 Displacement 136 in³ 177 in³ Rated Engine Speed 2600 rpm 2200 rpm Engine Power (Gross) 70 hp 68 hp PTO Power 62 hp 62.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid with recirculating bypass Liquid-cooled Air Cleaner 2-stage Dual dry Fuel System Common rail direct injection (CRDI) CRDI Alternator 75 A 95 A, 12 V ▶ HydraulicsPump Type Two engine-driven gear pumps, open center, fixed displacement Dual gear pump Implement Flow 12 gpm 10.3 gpm Steering Flow 5.5 gpm 5.8 gpm Total Hydraulic Flow 17.5 gpm 16.1 gpm Overall Hydraulic Pump Flow 17.5 gpm 16.1 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 6 (Floating/Regen); 4 (Spring/Floating) No. of Optional Remote Valves 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 18.5 gal Coolant Capacity 10.6 qt 2.8 gal Crankcase Capacity 6.7 qt Not Published Transmission / Hydraulic System Capacity ROPS 2WD: 6.1 gal; ROPS 4WD: 6.6 gal 11.1 gal Front Axle Fluid Capacity 4WD: 8.0 qt 4.3 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (540/540E optional) 540/750 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category II Hitch Lift Capacity 3,307 lb 4,270 lb Hitch Lift Capacity (at 24”) 2,701 lb 3,153 lb Lift Control Type Position control with mechanical draft control Position/Draft ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized shuttle Synchro or power shuttle No. of Speeds 8F/8R Not Published Max Travel Speed (Forward) 19.1 mph (13.6x28 rear tires); 19.8 mph (14.9x28 rear tires) 23 mph Max Travel Speed (Reverse) 20.2 mph (13.6x28 rear tires); 20.9 mph (14.9x28 rear tires) Not Published Clutch Dry, 11 in organic plate (LUK) M: Dry Single Plate; PS: Wet Multi Plate Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Individual mechanically actuated wet disc Wet disc Seat Suspension & Adjustability Deluxe contoured suspension seat, adjusts to operator height Suspension seat Front Axle Type 4WD: limited-slip front axle with front differential lock, mechanical engagement Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch ROPS 2WD: 129.5 in; ROPS 4WD: 134.0 in 155.6 in Overall Width ROPS 2WD: 66.5 in; ROPS 4WD: 67.5 in 72.4 in Wheelbase ROPS 2WD: 77.6 in; ROPS 4WD: 77.2 in 84.7 in Ground Clearance ROPS 2WD: 19.5 in; ROPS 4WD: 15.9 in 17.1 in Min. Turn Radius without Brakes ROPS 2WD: 122.0 in; ROPS 4WD: 190.9 in 162.2 in Height to Top of ROPS ROPS 2WD: 96.5 in; ROPS 4WD: 97.6 in Not Published Height to Top of ROPS (folded) ROPS 2WD: 75.9 in; ROPS 4WD: 77.0 in Not Published Height to Top of Cab Model Not Published 103 in ▶ WeightTractor Weight (Base) ROPS 2WD: 4,442 lb; ROPS 4WD: 5,059 lb 5,556 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf, R4 industrial Not Published R1 Agricultural - Front Not Published 9.5R20 R1 Agricultural - Rear 14.9x28 R1, 6 ply Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5x18 Not Published R4 Industrial - Rear 18.4x24 R4 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) Not Published Loader Model 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) L5068SL Loader Lift Height 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in L5068SL: 124.8 in Loader Lift Capacity (Full Height) 616TL: 1,940 lb; 621TL: 3,549 lb; 626TL: 2,447 lb (at the pivot pin, full height) L5068SL: 3,122 lb Loader Breakout Force 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in ahead of pivot pin) L5068SL: 5,225 lb ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months
