▶ EngineEngine Manufacturer FPT FPT Industrial Engine Model S8000 F5D Engine Type Turbocharged 3-cylinder diesel 4-cylinder diesel, turbocharged and aftercooled No. of Cylinders 3 4 Displacement 179 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 60 hp 65 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner PowerCore dry air cleaner Not Published Fuel System Bosch electronic high-pressure common rail Electronic high-pressure common rail fuel injection Alternator 120 A 120 A ▶ HydraulicsPump Type Dual gear pumps Open-center; dual pumps (implement + dedicated steering) Implement Flow 12.6 gpm 12.9 gpm Steering Flow 7.6 gpm 9.5 gpm Total Hydraulic Flow 20.2 gpm 22.4 gpm Overall Hydraulic Pump Flow 20.2 gpm 22.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 1 1 (third rear remote, DIA kit) ▶ Fluid CapacityFuel Tank Capacity 21.7 gal 23.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully independent, hydraulic wet clutch Fully independent hydraulic PTO Rear 540 rpm (540/540E optional) 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,500 lb (4,000 lb with optional auxiliary lift ram) 3,664 lb Lift Control Type Single-lever raise and lower with mechanical draft control (upper-link draft sensing) Mechanical draft control; single-lever raise and lower (standard) ▶ Transmission & DrivetrainTransmission Type 12x12 hydraulic power shuttle 12x12 power shuttle, column-mounted (standard); 20x20 power shuttle with creeper (optional) No. of Speeds 12F/12R 12F/12R (standard); 20F/20R with creeper (optional) Max Travel Speed (Forward) 25 mph 27 mph (4WD front axle); 20 mph (2WD front axle) Max Travel Speed (Reverse) Not Published Not Published Clutch 11 in single dry disc Not Published Differential Lock & Limited Slip Options Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement Mechanical rear differential lock (pedal); limited-slip 4WD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic-assist wet brakes Wet disc Seat Suspension & Adjustability Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: mechanical vinyl suspension seat Air-suspension cloth seat with armrests, 10° swivel (cab, standard); full-size folding instructor seat Front Axle Type 4WD (MFD) limited-slip front axle, electro-hydraulic engagement 4WD limited-slip front axle, electrohydraulic engagement (standard); heavy-duty 2WD front axle (optional) Front Axle Rating 6,500 lb dynamic capacity 9,480 lb (standard 4WD front axle, maximum capacity); 7,716 lb (optional 2WD heavy-duty front axle) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 154.1 in 152.9 in (2WD); 151.0 in (4WD) Overall Width Not Published 75.6 in Wheelbase 83.6 in 85.8 in (2WD); 83.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 134 in (2WD front axle) Height to Top of ROPS 99.8 in 104.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in 97.9 in ▶ WeightTractor Weight (Base) ROPS: 6,250 lb; Cab: 6,800 lb 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) 2WD: 7.50-16 front, 16.9R30 rear; 4WD: 11.2R24 front, 16.9R30 rear (standard ag tires) R1 Agricultural - Front 11.2x24 R1, 6 ply 2WD: 7.50-16; 4WD: 11.2R24 R1 Agricultural - Rear 16.9x30 R1, 6 ply 16.9R30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 R4, 10 ply Not Published R4 Industrial - Rear 19.5L-24 R4, 10 ply Not Published ▶ Loader & AttachmentsQuick Attach Loader System 72 in bucket with SSL (skid steer) or Euro-style quick attach Skid-steer-style quick-attach faceplate; on PowerStar 75, 710LU and 715LU come only with the skid-steer-style faceplate Loader Model 550LU (non self-leveling); 555LU (mechanical self-leveling) 710LU (NSL); 715LU (MSL) Loader Lift Height 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) 710LU: 126.3 in; 715LU: 125.9 in Loader Lift Capacity (Full Height) 550LU: 2,425 lb; 555LU: 3,153 lb (at max height, 31.5 in ahead of bucket pivot pin) 710LU: 3,461 lb; 715LU: 3,573 lb Loader Breakout Force Not Published 710LU: 3,739 lb; 715LU: 3,860 lb (31.5 in forward of the bucket pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
