▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNM74F 3TNM74F Engine Type Not Published 3 cylinder, water-cooled diesel, natural aspiration No. of Cylinders 3 3 Displacement 60.6 in³ 60.6 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21.5 hp 21.5 hp PTO Power 15.2 hp 15.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Single dry Single dry element Fuel System Indirect fuel injection Indirect injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Single gear pump with flow divider Single gear pump with flow divider Implement Flow 4.59 gpm 4.17 gpm Steering Flow 2.11 gpm 2.11 gpm Total Hydraulic Flow 6.71 gpm 6.3 gpm Overall Hydraulic Pump Flow 6.71 gpm 6.97 gpm Hydraulic System Type Live, independent Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity 3.7 qt 3.7 qt Crankcase Capacity 2.1 qt 2.1 qt Transmission / Hydraulic System Capacity 3.6 gal 3.6 gal Front Axle Fluid Capacity 2.6 qt 2.6 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2,000 rpm Optional, 2,500 rpm Category, 3-Point Hitch Category I Category I (limited) Hitch Lift Capacity 1,100 lb 1,100 lb Hitch Lift Capacity (at 24”) 679 lb 679 lb Lift Control Type Position Position control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Hydrostatic (HST) No. of Speeds 2 Range 2 range Max Travel Speed (Forward) 8.4 mph 7.8 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Electro-hydraulic PTO clutch assembly (hydrostatic drive, no traction clutch) Dry single plate Differential Lock & Limited Slip Options 4WD with differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, transmission and front axle support bolted together into a rigid assembly Sub-compact tractor Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Suspension seat with armrests & retractable seat belt Not Published Front Axle Type 4WD, center-pivot reverse Eliot type Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 44.5 in 44.5 in Wheelbase 53.1 in 53.1 in Ground Clearance 8.3 in 8.3 in Min. Turn Radius without Brakes 86.6 in 86.6 in Height to Top of ROPS 86.6 in 86.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 94.2 in (with 3-point hitch) 94.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,472 lb 1,433 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan: R4 Industrial (Std), R3 Turf (Opt), R14 (Opt) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front n/a 16x7.50-9 R1 Agricultural - Rear n/a 24x12.00-12 R3 Turf - Front 18x8.5-10 16x7.50-8 R3 Turf - Rear Not Published 26x12.00-12 R4 Industrial - Front Not Published 18x8.5-10 R4 Industrial - Rear Not Published 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System L72: skid-steer compatible quick-attach Quick attach front loader Loader Model L72 BBL100 Loader Lift Height L72: 72 in (maximum lift height) 78.5 in (at pivot pin) Loader Lift Capacity (Full Height) L72: 617 lb (to full height) 617 lb (at pivot pin) Loader Breakout Force L72: 1,285 lb 1,253 lbf ▶ WarrantyWarranty Length & Coverage Government and non-institutional: basic 24 months or 2,000 hours, powertrain 96 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Basic 24 months or 1,000 hours; powertrain 84 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours
