▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNM74F 3TNM74F-NCJT Engine Type Not Published Diesel No. of Cylinders 3 3 Displacement 60.6 in³ 60 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21.5 hp 21.5 hp PTO Power 15.2 hp 16.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Single dry Not Published Fuel System Indirect fuel injection Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Single gear pump with flow divider Gear Implement Flow 4.59 gpm 3.5 gpm Steering Flow 2.11 gpm 3.5 gpm Total Hydraulic Flow 6.71 gpm 7 gpm Overall Hydraulic Pump Flow 6.71 gpm 7 gpm Hydraulic System Type Live, independent Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 5.57 gal Coolant Capacity 3.7 qt Not Published Crankcase Capacity 2.1 qt Not Published Transmission / Hydraulic System Capacity 3.6 gal Not Published Front Axle Fluid Capacity 2.6 qt Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2,000 rpm Standard, 2100 rpm Category, 3-Point Hitch Category I Limited Category I Hitch Lift Capacity 1,100 lb Not Published Hitch Lift Capacity (at 24”) 679 lb 758 lb Lift Control Type Position Select control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Hydrostatic - 2 range No. of Speeds 2 Range Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) 8.4 mph 9.1 mph Max Travel Speed (Reverse) Not Published 9.1 mph Clutch Electro-hydraulic PTO clutch assembly (hydrostatic drive, no traction clutch) Not Published Differential Lock & Limited Slip Options 4WD with differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, transmission and front axle support bolted together into a rigid assembly Foldable ROPS, standard equipment Steering Hydrostatic power steering Power steering Brakes Wet disc Wet disc, left-hand pedal Seat Suspension & Adjustability Suspension seat with armrests & retractable seat belt Suspension seat, high back, adjustable settings; no tilt steering Front Axle Type 4WD, center-pivot reverse Eliot type Four-wheel drive (mechanical front-wheel drive) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 44.5 in 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 53.1 in 57.1 in Ground Clearance 8.3 in Not Published Min. Turn Radius without Brakes 86.6 in Not Published Height to Top of ROPS 86.6 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 94.2 in (with 3-point hitch) Not Published ▶ WeightTractor Weight (Base) 1,472 lb 1,475 lb (shipping weight, open station) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan: R4 Industrial (Std), R3 Turf (Opt), R14 (Opt) R3 Turf, R3 Hybrid, or R4 R1 Agricultural - Front n/a Not Published R1 Agricultural - Rear n/a Not Published R3 Turf - Front 18x8.5-10 18x8.50-10 R3 Turf - Rear Not Published 26x12-12 R4 Industrial - Front Not Published 18x8.5-10 R4 Industrial - Rear Not Published 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System L72: skid-steer compatible quick-attach Tool-free attach and park Loader Model L72 120R Loader Lift Height L72: 72 in (maximum lift height) 120R: 72 in Loader Lift Capacity (Full Height) L72: 617 lb (to full height) 120R (NSL): 704 lb (at pivot, full height) Loader Breakout Force L72: 1,285 lb Not Published ▶ WarrantyWarranty Length & Coverage Government and non-institutional: basic 24 months or 2,000 hours, powertrain 96 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Powertrain 6 years or 2,000 hours, standard at no cost, covers residential and commercial use
