▶ EngineEngine Manufacturer Yanmar YANMAR Engine Model 3TNM74F 3TNM74F Engine Type Not Published 4-cycle inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 60.6 in³ 60.6 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21.5 hp 21.5 hp PTO Power 15.2 hp 15.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid cooled Air Cleaner Single dry Not Published Fuel System Indirect fuel injection Not Published Alternator 40 A, 12 V 40 A ▶ HydraulicsPump Type Single gear pump with flow divider Dual hydraulic pump Implement Flow 4.59 gpm 4.3 gpm Steering Flow 2.11 gpm 3.7 gpm Total Hydraulic Flow 6.71 gpm 8.0 gpm (4.3 + 3.7, computed) Overall Hydraulic Pump Flow 6.71 gpm 8.0 gpm (4.3 + 3.7, computed) Hydraulic System Type Live, independent Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.1 gal Coolant Capacity 3.7 qt 3.0 qt Crankcase Capacity 2.1 qt 3.1 qt Transmission / Hydraulic System Capacity 3.6 gal 4.1 gal Front Axle Fluid Capacity 2.6 qt 3.2 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 554 rpm @ 3200 engine rpm Mid-PTO Availability 2,000 rpm Independent mid-PTO, 2057 rpm at 3200 engine rpm Category, 3-Point Hitch Category I Limited Category I Hitch Lift Capacity 1,100 lb Not Published Hitch Lift Capacity (at 24”) 679 lb 660 lb Lift Control Type Position Select control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Hydrostatic transmission No. of Speeds 2 Range Infinite forward and reverse (hydrostatic); 1 range Max Travel Speed (Forward) 8.4 mph 8.6 mph (with R4 tires) Max Travel Speed (Reverse) Not Published 6.3 mph (with R4 tires) Clutch Electro-hydraulic PTO clutch assembly (hydrostatic drive, no traction clutch) Not Published Differential Lock & Limited Slip Options 4WD with differential lock Differential lock pedal (optional) ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, transmission and front axle support bolted together into a rigid assembly Full-frame chassis Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Suspension seat with armrests & retractable seat belt Fore-and-aft adjustable operator seat Front Axle Type 4WD, center-pivot reverse Eliot type Selectable 2WD/4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 44.5 in 47.3 in (with R4 tires) Wheelbase 53.1 in 57.9 in Ground Clearance 8.3 in 6.4 in (with R4 tires) Min. Turn Radius without Brakes 86.6 in 7.87 ft Height to Top of ROPS 86.6 in 82.3 in (with R4 tires) Height to Top of ROPS (folded) Not Published 66.3 in (folded ROPS, top of steering wheel, R4 tires) Height to Top of Cab Model Not Published Not Published Overall Length 94.2 in (with 3-point hitch) 102.1 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,472 lb 1,537 lb (with ROPS, R4 tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan: R4 Industrial (Std), R3 Turf (Opt), R14 (Opt) R3 Turf; R4 Industrial R1 Agricultural - Front n/a Not Published R1 Agricultural - Rear n/a Not Published R3 Turf - Front 18x8.5-10 18x8.50-10 4PR R3 Turf - Rear Not Published 26x12.0-12 4PR R4 Industrial - Front Not Published 18x8.50-10 6PR R4 Industrial - Rear Not Published 26x12.0-12 4PR ▶ Loader & AttachmentsQuick Attach Loader System L72: skid-steer compatible quick-attach YL110: YANMAR quick attachment system Loader Model L72 YL110 Loader Lift Height L72: 72 in (maximum lift height) YL110: 71 in to pivot pin (51 in under level bucket) Loader Lift Capacity (Full Height) L72: 617 lb (to full height) YL110: 825 lb at pivot pin Loader Breakout Force L72: 1,285 lb YL110: 1,342 lb at pivot pin ▶ WarrantyWarranty Length & Coverage Government and non-institutional: basic 24 months or 2,000 hours, powertrain 96 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Private individual use: basic 24 months or 2,000 hours, powertrain 10 years or 3,000 hours; attachments 1 year
