▶ EngineEngine Manufacturer Yanmar Yanmar Yanmar Engine Model 3TNV80F 3TNV80F-CJT 3TNV80F Engine Type Water cooled, 4-cycle diesel 3-cylinder, liquid-cooled diesel 3-cylinder, naturally aspirated, liquid-cooled diesel No. of Cylinders 3 3 3 Displacement 77.3 in³ 77.3 in³ 77.3 in³ Rated Engine Speed 3000 rpm 3200 rpm 3000 rpm Engine Power (Gross) 24 hp 23.9 hp 24.7 hp PTO Power 18.8 hp 18 hp 17.2 hp Engine Emissions Constraints Tier 4 Tier 4 Tier 4 Cooling System Type Water cooled, forced circulation Liquid-cooled Pressurized liquid with recirculating bypass Air Cleaner Single element Dry with safety element Single-element Fuel System Indirect fuel injection Indirect injection In-line injection pump, indirect injection (swirl chamber) Alternator 40 A, 12 V 40 A, 12 V 50 A ▶ HydraulicsPump Type Not Published Gear Gear Implement Flow 4.18 gpm 3.5 gpm 4.6 gpm Steering Flow 2.77 gpm 3.5 gpm 2.1 gpm Total Hydraulic Flow 6.95 gpm 7 gpm 6.7 gpm Overall Hydraulic Pump Flow 6.95 gpm 6.3 gpm 6.7 gpm Hydraulic System Type Live, independent Open center Open center Rear Remote Hydraulic Flow Not Published 3.5 gpm implement circuit; total 7 gpm Not Published No. of Standard Remote Valves 1 Not Published Not Published No. of Optional Remote Valves Not Published Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 5.81 gal 6.3 gal 6.6 gal Coolant Capacity 0.96 gal 3.9 qt 3.49 qt Crankcase Capacity 0.71 gal 2.9 qt 3 qt Transmission / Hydraulic System Capacity 3.83 gal 3.25 gal 3.3 gal Front Axle Fluid Capacity 0.85 gal 3.0 qt 0.5 gal ▶ PTO & HitchPTO Type Independent Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm 540 rpm Mid-PTO Availability 2,000 rpm Standard, 2100 rpm Standard (2,500 rpm) Category, 3-Point Hitch Category I Limited Category I Category I Hitch Lift Capacity 1,323 lb 1,177 lb 992 lb Hitch Lift Capacity (at 24”) 1,058 lb 758 lb 728 lb Lift Control Type Position Position control Lift-hold-lower ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Hydrostatic - 2 range 2-range hydrostatic, dual pedal No. of Speeds 2 ranges (high/low), infinite forward and reverse Infinite (hydrostatic), 2 ranges forward and reverse Infinite (2 ranges) Max Travel Speed (Forward) 11.2 mph 9.1 mph 9.1 mph Max Travel Speed (Reverse) Not Published 9.1 mph 5.5 mph Clutch Electro-hydraulic PTO clutch assembly (hydrostatic drive, no traction clutch) wet disc Not Published Differential Lock & Limited Slip Options 4WD with differential lock (bevel gears with diff-lock) Standard rear differential lock Mechanical, foot-operated rear differential lock ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, transmission and front axle support bolted together into a rigid assembly Semi-flat platform; two-post folding ROPS; four-wheel drive Not Published Steering Hydrostatic power steering Power steering Hydrostatic power steering Brakes Wet disc, independent foot pedals that lock together Wet disk, left-hand pedal Wet, multi-disc Seat Suspension & Adjustability Suspension seat with armrests & retractable seat belt Deluxe suspension seat with armrests and tilt steering wheel Deluxe high-back seat with armrests and adjustable backrest Front Axle Type 4WD, center-pivot reverse Eliot type 4WD (MFWD), on-the-go engagement 4WD Front Axle Rating Not Published 1,349 lb Not Published Drawbar Capacity Not Published 2,165 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 45.8 in 47.22 in (R3 tires); 47.32 in (R4 tires) 46.7 in Wheelbase 57.5 in 57.1 in 56.1 in Ground Clearance 9.4 in 7.7 in (front axle) 12 in Min. Turn Radius without Brakes Not Published 7.4 ft (no brakes, no MFWD) 94 in Height to Top of ROPS 91.3 in 90 in (ROPS extended, R4 tires) 87.4 in Height to Top of ROPS (folded) Not Published 73 in 64 in Height to Top of Cab Model Not Published Not Published 87.4 in Overall Length 100.5 in 108 in 97.4 in ▶ WeightTractor Weight (Base) 1,610 lb 1,556 lb ROPS: 1,444 lb; Cab: 1,805 lb Weight with ROPS and Loader 2,091 lb (1,610 + 481, computed) Not Published Not Published Weight with Cab and Loader Not Published Not Published Not Published ▶ Tire OptionsTire Size & Options Titan: R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt), R14 (Opt) Standard R4, optional R3 R3 Turf, R4 Industrial R1 Agricultural - Front 6-12 Not Published Not Published R1 Agricultural - Rear 9.5-16 Not Published Not Published R3 Turf - Front 20x8-10 18x8.5-10 18x8.50-10 R3 Turf - Rear 29x12.5-15 26x12-12 26x12.0-12 R4 Industrial - Front 20x8-10 18x8.5-10 18x8.50-10 R4 Industrial - Rear 27x12.5-15 26x12-12 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System L75: skid-steer compatible quick-attach Tool-free attach and park (MSL optional on 120R) 100LC: Quick Mount system, no tools needed Loader Model L75 120R (MSL or NSL); 120E (NSL only) 100LC Loader Lift Height L75: 75.3 in (maximum lift height to pivot pin) 120R: 72 in; 120E: 71.2 in 100LC: 72 in (at pivot pin) Loader Lift Capacity (Full Height) L75: 947 lb (at pivot pin, to full height) 120R (MSL): 680 lb; 120E (NSL): 519 lb (at 19.7 in ahead of pivot) 100LC: 1,005 lb (at bucket pivot pin, max height) Loader Breakout Force L75: 1,680 lb (at pivot pin) Not Published 100LC: 2,078 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Government and non-institutional: basic 24 months or 2,000 hours, powertrain 96 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Powertrain 6 years, standard at no cost, covers residential and commercial use Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total ▶ ITC Company AccessoriesAccessories that fit None tagged yet None tagged yet
