▶ EnginePTO Power 18.8 hp 18.2 hp Alternator 40 A, 12 V 40 A, 12 V Air Cleaner Single element Dual element Engine Type Water cooled, 4-cycle Diesel Diesel Fuel System Indirect Fuel Injection Indirect injection Displacement 77.3 in³ 77.3 in³ Engine Model 3TNV80F-SDKTFF — No. of Cylinders 3 3 Rated Engine Speed 3000 rpm 3200 rpm Cooling System Type Water cooled, forced circulation Water pump (liquid-cooled) Engine Manufacturer Yanmar Yanmar Engine Power (Gross) 23.9 hp 23.9 hp @ 200 rpm Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader 2,091 lb ~2,005 lb (open station shipping weight 1,872 lb / 1,871.7 lb base; with H130 loader approx. 2,005 lb estimated) Weight with Cab and Loader Not Published ~2,392 lb base cab shipping weight (loader weight additive) ▶ WarrantyWarranty Length & Coverage Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) 2-year bumper-to-bumper (comprehensive) + 6-year/2,000-hour powertrain warranty ▶ HydraulicsPump Type Gear Pump Gear Steering Flow Not Published 3.5 gpm Implement Flow Not Published 3.5 gpm Total Hydraulic Flow 6.95 gpm 5.6 gpm 21.2 lpm Hydraulic System Type Hydrostatic Open center Rear Remote Hydraulic Flow Not Published 3.4 gpm implement circuit; 7.0 gpm combined pump output Overall Hydraulic Pump Flow 26.3 lpm (6.95 US gpm) 3.4 gpm 12.9 lpm No. of Optional Remote Valves NOT FOUND — no source explicitly states the number of optional remote valves available for the RK24. Sources confirm 1 standard rear remote set is included, but do not specify optional add-on valve counts. 2 No. of Standard Remote Valves 1 0 ▶ PTO & HitchPTO Rear 540 rpm 540 rpm PTO Type Independent PTO independent Lift Control Type Position control position control Hitch Lift Capacity 1,323 lb 915 lb Mid-PTO Availability Standard, 2,000 rpm @ 2,875 rpm Mid - 2100 rpm Category, 3-Point Hitch Category I Limited Category 1 Hitch Lift Capacity (at 24”) Not Published 915 lb ▶ Tire OptionsR3 Turf - Rear 29X12.5-15 12-16.5 or R3 Radial: 280/70 R16 R3 Turf - Front 20X8-10 23x8.50-12 or R3 Radial: 220/55-R12 Tire Size & Options R4 Industrial (Std), R3 Turf (Opt) R1 Ag (Opt), Goodyear R14 (Opt) Front: 23x8.5-12 (R4 industrial / R3 turf); Rear: 31x12-16.5 (R4 industrial / R3 turf) R4 Industrial - Rear 27X12.5-15 12-16.5 R4 Industrial - Front 20X8-10 23x8.50-12 R1 Agricultural - Rear 9.5-16 Not separately listed; industrial R4 rear: 31x12.00-16.5 R1 Agricultural - Front 6-12 Not separately listed; industrial R4 front: 23x8.50-12 ▶ Fluid CapacityCoolant Capacity 3.6 ℓ (0.96US gal) 0.84 gal Crankcase Capacity 2.7 ℓ ( 0.71 US gal) 0.84 gal Fuel Tank Capacity 5.81 gal 6.1 gal Front Axle Fluid Capacity 3.2ℓ (0.85 US gal) 0.89 gal Transmission / Hydraulic System Capacity 14.5ℓ (3.83 US gal) 3.5 gal ▶ Loader & AttachmentsLoader Lift Height 75.3 Gen 1 (H130): 78.9 in at pin; Gen 2 (120R): 72 in at pivot Loader Breakout Force 1,680 lb Gen 1 (H130): 2,508 lb at pin; Gen 2 (120R): 1,963 lb at pivot Quick Attach Loader System Skid-Steer Compatible Quick-Attach Quick-park / quick-attach system (H130 loader on Gen 1; 120R loader on Gen 2) Loader Lift Capacity (Full Height) 947 lb Gen 1 (H130): 1,023 lb at pin; Gen 2 (120R): 754 lb at pivot ▶ Transmission & DrivetrainClutch Not Published wet disc No. of Speeds 2 Range (High/Low) Two range (Hi and Lo) Transmission Type Hydraulic + Mechanical H/L with constant-mesh Hydrostatic - two range Max Travel Speed (Forward) 10.5 mph 12.3 mph Max Travel Speed (Reverse) Not Published 11.4 mph Differential Lock & Limited Slip Options Differential lock (bevel gears with diff-lock) Differential lock: Yes; Limited slip differential: No ▶ Chassis, Steering & ControlsBrakes Wet Disc, Foot operated, independent with provision of inter lock for simultaneous operation Wet disc Steering Hydrostatic Power steering system Power steering Frame Type Not Published Open center; spur gear final drive; wet disc brakes Front Axle Type Center-pivot, reverse Eliot type Four-wheel drive Drawbar Capacity Not Published Not Published Front Axle Rating Not Published 1349 lb Seat Suspension & Adjustability Not Published Fore/aft adjustable; seat flips forward for weather protection; no mechanical suspension listed ▶ Dimensions & ManeuverabilityWheelbase 57.5 in 63 in. Overall Width 45.8 in Not Published Ground Clearance 9.4 in 12.5 in Height to Top of ROPS 91.3 in Two-post foldable ROPS (folded/upright height not confirmed in sources) Height to Top of Cab Model Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published 2.51 m 8.2 ft Overall Length with 3-Point Hitch 100.5 in 109.2 in ▶ ITC Company AccessoriesAccessories that fit None tagged yet
