▶ EngineEngine Manufacturer Yanmar YANMAR Engine Model 3TNV80F-SDKTFF 3TNV88F-EPLST Engine Type Water cooled, 4-cycle Diesel 3-cylinder, liquid-cooled, diesel, naturally aspirated, DI No. of Cylinders 3 3 Displacement 77.3 in³ 100.2 in³ Rated Engine Speed 3000 rpm 2400 rpm Engine Power (Gross) 23.9 hp 23.9 hp PTO Power 18.8 hp 19 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water cooled, forced circulation Liquid-cooled Air Cleaner Single element Dry Fuel System Indirect Fuel Injection DI (direct injection) Alternator 40 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Gear Pump Gear pump Implement Flow Not Published 6.1 gpm Steering Flow Not Published 4.6 gpm Total Hydraulic Flow 6.95 gpm 10.7 gpm Overall Hydraulic Pump Flow 6.95 gpm 10.7 gpm Hydraulic System Type Hydrostatic Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 pair No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 5.81 gal 11.4 gal Coolant Capacity 3.6 ℓ (0.96US gal) Not Published Crankcase Capacity 2.7 ℓ ( 0.71 US gal) Not Published Transmission / Hydraulic System Capacity 14.5ℓ (3.83 US gal) Not Published Front Axle Fluid Capacity 3.2ℓ (0.85 US gal) Not Published ▶ PTO & HitchPTO Type Independent PTO Independent PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Standard, 2,000 rpm @ 2,875 rpm Available (option) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,323 lb 1,808 lb Hitch Lift Capacity (at 24”) Not Published 1433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydraulic + Mechanical H/L with constant-mesh HST No. of Speeds 2 Range (High/Low) 3 ranges Max Travel Speed (Forward) 10.5 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock (bevel gears with diff-lock) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering system Hydrostatic power steering Brakes Wet Disc, Foot operated, independent with provision of inter lock for simultaneous operation Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Center-pivot, reverse Eliot type Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 100.5 in 125 in Overall Width 45.8 in 66 in Wheelbase 57.5 in 69 in Ground Clearance 9.4 in Not Published Min. Turn Radius without Brakes Not Published 11.5 ft (3.5 m) Height to Top of ROPS 91.3 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 90 in ▶ WeightWeight with ROPS and Loader 2,091 lb Not Published Weight with Cab and Loader Not Published Not Published Tractor Weight (Base) n/a 3,609 lb ▶ Tire OptionsTire Size & Options R4 Industrial (Std), R3 Turf (Opt) R1 Ag (Opt), Goodyear R14 (Opt) R1 agricultural, R4 industrial, R3 turf and VT (versa turf); VT same size as R4 R1 Agricultural - Front 6-12 7-14 R1 Agricultural - Rear 9.5-16 11.2-24 R3 Turf - Front 20X8-10 25x8.50-14 R3 Turf - Rear 29X12.5-15 41x14.00-20 R4 Industrial - Front 20X8-10 27x8.50-15 R4 Industrial - Rear 27X12.5-15 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Skid-Steer Compatible Quick-Attach LL3001, LL3002: ISO 24410 Quick Attaching Coupler Loader Lift Height 75.3 LL3002: 94.3 in Loader Lift Capacity (Full Height) 947 lb LL3002: 1,599 lb Loader Breakout Force 1,680 lb LL3002: 2,962 lb Loader Model n/a LL3002 ▶ WarrantyWarranty Length & Coverage Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
