▶ EngineEngine Manufacturer Yanmar Kukje Engine Model 3TNV80F A1100N2 Engine Type Water cooled, 4-cycle diesel Four-stroke, naturally aspirated, indirect injection, water-cooled diesel No. of Cylinders 3 3 Displacement 77.3 in³ 71.7 in³ Rated Engine Speed 3000 rpm 2600 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 18.8 hp 16.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water cooled, forced circulation Water-cooled Air Cleaner Single element Not Published Fuel System Indirect fuel injection Indirect Injection Alternator 40 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 4.18 gpm 4.5 gpm Steering Flow 2.77 gpm Not Published Total Hydraulic Flow 6.95 gpm 7.1 gpm Overall Hydraulic Pump Flow 6.95 gpm 7.1 gpm Hydraulic System Type Live, independent Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 5.81 gal 5.8 gal Coolant Capacity 0.96 gal 3.7 qt Crankcase Capacity 0.71 gal 2.3 qt Transmission / Hydraulic System Capacity 3.83 gal 15.3 qt Front Axle Fluid Capacity 0.85 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 @ 2550 rpm Mid-PTO Availability 2,000 rpm Available; 2000 @ 2550 rpm Category, 3-Point Hitch Category I CAT I with Check Chains Hitch Lift Capacity 1,323 lb 1,323 lb Hitch Lift Capacity (at 24”) 1,058 lb Not Published Lift Control Type Position Not Published ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic HST - 2 range No. of Speeds 2 ranges (high/low), infinite forward and reverse Infinite Max Travel Speed (Forward) 11.2 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Electro-hydraulic PTO clutch assembly (hydrostatic drive, no traction clutch) Dry-Single Differential Lock & Limited Slip Options 4WD with differential lock (bevel gears with diff-lock) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, transmission and front axle support bolted together into a rigid assembly Not Published Steering Hydrostatic power steering Power steering Brakes Wet disc, independent foot pedals that lock together Wet Disc Seat Suspension & Adjustability Suspension seat with armrests & retractable seat belt Not Published Front Axle Type 4WD, center-pivot reverse Eliot type Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 45.8 in 45.8 in Wheelbase 57.5 in 57.5 in Ground Clearance 9.4 in 9.4 in Min. Turn Radius without Brakes Not Published 7.2 ft Height to Top of ROPS 91.3 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 78.2 in Overall Length 100.5 in 100.5 in ▶ WeightTractor Weight (Base) 1,610 lb 1,638 lb Weight with ROPS and Loader 2,091 lb (1,610 + 481, computed) Not Published Weight with Cab and Loader Not Published 2,419 lb (1,870 + 549, computed; 25LSK loader shipping weight) ▶ Tire OptionsTire Size & Options Titan: R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt), R14 (Opt) AG, IND, TURF R1 Agricultural - Front 6-12 6x12 R1 Agricultural - Rear 9.5-16 9.5x16 R3 Turf - Front 20x8-10 20x8-10 R3 Turf - Rear 29x12.5-15 29x12.5-15 R4 Industrial - Front 20x8-10 20x8-10 R4 Industrial - Rear 27x12.5-15 27x12.5-15 ▶ Loader & AttachmentsQuick Attach Loader System L75: skid-steer compatible quick-attach 25LSK: Skid steer style quick coupler, standard Loader Model L75 25LSK Loader Lift Height L75: 75.3 in (maximum lift height to pivot pin) 25LSK: 75.3 in Loader Lift Capacity (Full Height) L75: 947 lb (at pivot pin, to full height) 25LSK: 900 lb Loader Breakout Force L75: 1,680 lb (at pivot pin) 25LSK: 2,000 lb ▶ WarrantyWarranty Length & Coverage Government and non-institutional: basic 24 months or 2,000 hours, powertrain 96 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit
