▶ EngineEngine Manufacturer Yanmar Shibaura Engine Model 3TNV80F Not Published Engine Type Water cooled, 4-cycle diesel 3-cylinder diesel, liquid-cooled No. of Cylinders 3 3 Displacement 77.3 in³ 91.5 in³ Rated Engine Speed 3000 rpm 2600 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 18.8 hp 19.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water cooled, forced circulation Liquid-cooled Air Cleaner Single element Not Published Fuel System Indirect fuel injection Indirect low-pressure injection Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Gear-type pump Implement Flow 4.18 gpm Not Published Steering Flow 2.77 gpm 3.8 gpm Total Hydraulic Flow 6.95 gpm 10.5 gpm Overall Hydraulic Pump Flow 6.95 gpm Not Published Hydraulic System Type Live, independent Open center Rear Remote Hydraulic Flow Not Published 6.7 gpm No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Not Published Up to 2 ▶ Fluid CapacityFuel Tank Capacity 5.81 gal 10.04 gal Coolant Capacity 0.96 gal 1.32 gal Crankcase Capacity 0.71 gal 1.22 gal Transmission / Hydraulic System Capacity 3.83 gal 10.04 gal Front Axle Fluid Capacity 0.85 gal 1.48 gal ▶ PTO & HitchPTO Type Independent Transmission driven PTO Rear 540 rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability 2,000 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,323 lb 2,205 lb Hitch Lift Capacity (at 24”) 1,058 lb 1,600 lb Lift Control Type Position Not Published ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic 9 x 3 mechanical shift constant mesh gears or 3-range hydrostatic No. of Speeds 2 ranges (high/low), infinite forward and reverse Gear: 9F / 3R; HST: 3-range infinite Max Travel Speed (Forward) 11.2 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Electro-hydraulic PTO clutch assembly (hydrostatic drive, no traction clutch) Gear: dry single disc Differential Lock & Limited Slip Options 4WD with differential lock (bevel gears with diff-lock) Mechanical engagement via heel pedal ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, transmission and front axle support bolted together into a rigid assembly Not Published Steering Hydrostatic power steering Power steering Brakes Wet disc, independent foot pedals that lock together Internal wet brakes, single brake pedal on HST, two brake pedals on gear models Seat Suspension & Adjustability Suspension seat with armrests & retractable seat belt Suspended vinyl seat with retractable seatbelt, fixed steering wheel Front Axle Type 4WD, center-pivot reverse Eliot type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 45.8 in 52.4 in Wheelbase 57.5 in 65.9 in Ground Clearance 9.4 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 91.3 in 97.6 in Height to Top of ROPS (folded) Not Published 63.8 in Height to Top of Cab Model Not Published Not Published Overall Length 100.5 in 116 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 1,610 lb HST: 2,657 lb Weight with ROPS and Loader 2,091 lb (1,610 + 481, computed) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan: R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt), R14 (Opt) Not Published R1 Agricultural - Front 6-12 Not Published R1 Agricultural - Rear 9.5-16 Not Published R3 Turf - Front 20x8-10 Not Published R3 Turf - Rear 29x12.5-15 Not Published R4 Industrial - Front 20x8-10 Not Published R4 Industrial - Rear 27x12.5-15 Not Published ▶ Loader & AttachmentsQuick Attach Loader System L75: skid-steer compatible quick-attach L105E: skid steer or pin-type implement attachments Loader Model L75 L105E Loader Lift Height L75: 75.3 in (maximum lift height to pivot pin) L105E: 95.7 in (at pivot pin) Loader Lift Capacity (Full Height) L75: 947 lb (at pivot pin, to full height) L105E: 1,210 lb (at pivot pin, full height) Loader Breakout Force L75: 1,680 lb (at pivot pin) L105E: 1,460 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Government and non-institutional: basic 24 months or 2,000 hours, powertrain 96 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours 5-year powertrain warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
