▶ EngineEngine Manufacturer Yanmar Iseki Engine Model 3TNV80F Not Published Engine Type Water cooled, 4-cycle diesel 3-cylinder diesel No. of Cylinders 3 3 Displacement 77.3 in³ 90.9 in³ Rated Engine Speed 3000 rpm 2600 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 18.8 hp Mech: 20.4 hp; HST: 19.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water cooled, forced circulation Liquid cooled Air Cleaner Single element Not Published Fuel System Indirect fuel injection Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Two gear-type pumps Implement Flow 4.18 gpm 7.3 gpm Steering Flow 2.77 gpm 3.6 gpm Total Hydraulic Flow 6.95 gpm 10.9 gpm (7.3 + 3.6, computed) Overall Hydraulic Pump Flow 6.95 gpm 10.9 gpm (7.3 + 3.6, computed) Hydraulic System Type Live, independent Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 5.81 gal 10 gal Coolant Capacity 0.96 gal Not Published Crankcase Capacity 0.71 gal Not Published Transmission / Hydraulic System Capacity 3.83 gal Not Published Front Axle Fluid Capacity 0.85 gal Not Published ▶ PTO & HitchPTO Type Independent Mech: Independent; HST: Transmission PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2,000 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,323 lb 2,205 lb Hitch Lift Capacity (at 24”) 1,058 lb 1,598 lb Lift Control Type Position Not Published ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Mech: 8x8 synchro shuttle; HST: 3-range hydrostatic No. of Speeds 2 ranges (high/low), infinite forward and reverse Mech: 8x8 synchro shuttle; HST: 3-range hydrostatic Max Travel Speed (Forward) 11.2 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Electro-hydraulic PTO clutch assembly (hydrostatic drive, no traction clutch) Not Published Differential Lock & Limited Slip Options 4WD with differential lock (bevel gears with diff-lock) Not Published ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, transmission and front axle support bolted together into a rigid assembly Not Published Steering Hydrostatic power steering Power steering Brakes Wet disc, independent foot pedals that lock together Not Published Seat Suspension & Adjustability Suspension seat with armrests & retractable seat belt Not Published Front Axle Type 4WD, center-pivot reverse Eliot type Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 45.8 in 52.4 in Wheelbase 57.5 in Not Published Ground Clearance 9.4 in 11 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 91.3 in 97.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 100.5 in 116.5 in ▶ WeightTractor Weight (Base) 1,610 lb 2,668 lb Weight with ROPS and Loader 2,091 lb (1,610 + 481, computed) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan: R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt), R14 (Opt) Not Published R1 Agricultural - Front 6-12 Not Published R1 Agricultural - Rear 9.5-16 Not Published R3 Turf - Front 20x8-10 Not Published R3 Turf - Rear 29x12.5-15 Not Published R4 Industrial - Front 20x8-10 Not Published R4 Industrial - Rear 27x12.5-15 Not Published ▶ Loader & AttachmentsQuick Attach Loader System L75: skid-steer compatible quick-attach Skid steer quick attach Loader Model L75 FL2407X Loader Lift Height L75: 75.3 in (maximum lift height to pivot pin) FL2407X: 94.3 in (at pivot pin) Loader Lift Capacity (Full Height) L75: 947 lb (at pivot pin, to full height) FL2407X: 1,450 lb (to maximum height, at pivot pin) Loader Breakout Force L75: 1,680 lb (at pivot pin) FL2407X: 2,288 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Government and non-institutional: basic 24 months or 2,000 hours, powertrain 96 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
