▶ EngineEngine Manufacturer YANMAR Yanmar Engine Model 3TNV80F 3TNV80F Engine Type Diesel 3-cylinder, indirect injection (swirl chamber), water-cooled No. of Cylinders 3 3 Displacement 77.3 in³ 77.3 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 24.7 hp 24.7 hp PTO Power 18.3 PTO HP 17.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dry Fuel System Fuel injection In-line injection pump Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump Gear pump, transmission driven Implement Flow 4.18 GPM 4.6 gpm Steering Flow 2.77 GPM 2.1 gpm Total Hydraulic Flow 6.95 gpm 6.7 gpm Overall Hydraulic Pump Flow 6.95 gpm 6.7 gpm Hydraulic System Type Live independent Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 0 No. of Optional Remote Valves Not Published 1 pair (2 quick couplers) ▶ Fluid CapacityFuel Tank Capacity 25 ℓ (6.6 gal) 6.6 gal Coolant Capacity 3.6 ℓ (3.8 quart) 0.9 gal Crankcase Capacity 2.7 ℓ (2.9 quart) 0.8 gal Transmission / Hydraulic System Capacity 14 ℓ (5.8 gal) 3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe) Front Axle Fluid Capacity 4.5 ℓ (4.7 quart) 0.5 gal ▶ PTO & HitchPTO Type INDEPENDENT Independent (electro-hydraulic) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Not Published Standard (2,500 rpm) Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity 1,534.4 lb (1,534 lb.) 970 lb Hitch Lift Capacity (at 24”) 1,102 lb 728 lb Lift Control Type POSITION Position control ▶ Transmission & DrivetrainTransmission Type 2-Range Hydrostatic Transmission Hydrostatic Drive No. of Speeds 2 Range (H/L) 2 ranges Max Travel Speed (Forward) 13.7 mph (13.7 m/h) 8.70 mph Max Travel Speed (Reverse) Not Published 5.22 mph Clutch Not Applicable Not Published Differential Lock & Limited Slip Options Differential lock Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Rigid frame Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes WET DISC Wet, multi-disc Seat Suspension & Adjustability Not Published Forward/backward adjustable via seat F/R adjustment lever; reversible seat optional Front Axle Type 4WD front axle Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 107.9 in (107.8 in) 97 in Overall Width 52.8 in (52.8 in) 47 in Wheelbase Not Published 56 in Ground Clearance 7.7 in (7.71 in) Not Published Min. Turn Radius without Brakes 109.5 in (109.5 in) 7.87 ft Height to Top of ROPS 89.8 in 87 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published ▶ WeightWeight with ROPS and Loader 2,560 lb Not Published Weight with Cab and Loader Not Published Not Published Tractor Weight (Base) n/a 1,444 lb ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf R1 Agricultural - Front 6.0-12 Not Published R1 Agricultural - Rear 9.5-20 Not Published R3 Turf - Front 25X8.50-14 18x8.50-10 R3 Turf - Rear 36x13.5-15 26x12.0-12 R4 Industrial - Front 23X8.50-12; 25X8.50-14 18x8.50-10 R4 Industrial - Rear 12-16.5 | 14-17.5 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System L85: Skid-steer compatible quick-attach LL1101 Quick-Attach Front Loader Loader Lift Height 87" LL1101: 72.0 in; LL1100: 72.0 in (at pivot pin) Loader Lift Capacity (Full Height) 1,380 lb. LL1101: 966 lb; LL1100: 1,005 lb (at pivot pin, maximum height) Loader Breakout Force 2,059 lb. LL1101: 1,960 lb; LL1100: 2,083 lb (at pivot pin) Loader Model n/a LL1101; LL1100 ▶ WarrantyWarranty Length & Coverage Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) 6-year limited warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
