▶ EngineEngine Manufacturer YANMAR Yanmar Engine Model 3TNV80F 3TNV80F-ZXKLST Engine Type Diesel 3-cylinder, indirect injection (swirl chamber), liquid-cooled No. of Cylinders 3 3 Displacement 77.3 in³ 77.3 in³ Rated Engine Speed 3000 rpm 2800 rpm Engine Power (Gross) 24.7 hp 24.7 hp PTO Power 18.3 PTO HP 19.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Fuel injection In-line injection pump Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump Gear pump, engine driven Implement Flow 4.18 GPM 5.6 gpm Steering Flow 2.77 GPM 3.7 gpm Total Hydraulic Flow 6.95 gpm 9.3 gpm Overall Hydraulic Pump Flow 6.95 gpm 9.3 gpm Hydraulic System Type Live independent Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 0 No. of Optional Remote Valves Not Published 1 pair (optional) ▶ Fluid CapacityFuel Tank Capacity 25 ℓ (6.6 gal) 6.79 gal Coolant Capacity 3.6 ℓ (3.8 quart) 0.9 gal Crankcase Capacity 2.7 ℓ (2.9 quart) 0.8 gal Transmission / Hydraulic System Capacity 14 ℓ (5.8 gal) 4.5 gal Front Axle Fluid Capacity 4.5 ℓ (4.7 quart) 0.8 gal ▶ PTO & HitchPTO Type INDEPENDENT Independent (electro-hydraulic) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Not Published Optional (2,500 rpm) Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity 1,534.4 lb (1,534 lb.) 1,896 lb Hitch Lift Capacity (at 24”) 1,102 lb 1,323 lb Lift Control Type POSITION Position control ▶ Transmission & DrivetrainTransmission Type 2-Range Hydrostatic Transmission Hydrostatic Drive No. of Speeds 2 Range (H/L) 3 ranges Max Travel Speed (Forward) 13.7 mph (13.7 m/h) 12.86 mph Max Travel Speed (Reverse) Not Published 8.45 mph Clutch Not Applicable Not Published Differential Lock & Limited Slip Options Differential lock Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Rigid frame Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes WET DISC Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD front axle Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 107.9 in (107.8 in) 111.9 in Overall Width 52.8 in (52.8 in) 48.7 in Wheelbase Not Published 63.4 in Ground Clearance 7.7 in (7.71 in) Not Published Min. Turn Radius without Brakes 109.5 in (109.5 in) 8.2 ft (with brake applied) Height to Top of ROPS 89.8 in 86.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published ▶ WeightWeight with ROPS and Loader 2,560 lb Not Published Weight with Cab and Loader Not Published Not Published Tractor Weight (Base) n/a 1,764 lb ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 6.0-12 7-12 R1 Agricultural - Rear 9.5-20 11.2-16 R3 Turf - Front 25X8.50-14 22x8.50-12 R3 Turf - Rear 36x13.5-15 31x15.50-15 R4 Industrial - Front 23X8.50-12; 25X8.50-14 23x8.50-12 R4 Industrial - Rear 12-16.5 | 14-17.5 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System L85: Skid-steer compatible quick-attach LL2300: Bobcat-type (skid-steer style) quick attach bucket carrier; LL2001: Not Published Loader Lift Height 87" LL2300: 84.4 in; LL2001: 84.4 in Loader Lift Capacity (Full Height) 1,380 lb. LL2300: 1,067 lb; LL2001: 1,127 lb (at pivot pin) Loader Breakout Force 2,059 lb. LL2300: 2,290 lb; LL2001: 1,744 lb (at pivot pin) Loader Model n/a LL2300; LL2001 ▶ WarrantyWarranty Length & Coverage Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) 6-year limited warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
