▶ EnginePTO Power 18.3 PTO HP 18.5 hp Alternator 40 A, 12 V 50 A, 12 V Air Cleaner Not Published Dry Engine Type Diesel 3-cylinder, Indirect-injection (swirl chamber), Water-cooled Fuel System Fuel injection Indirect injection (in-line pump) Displacement 77.3 in³ 80.4 in³ Engine Model 3TNV80F — No. of Cylinders 3 3 Rated Engine Speed 3000 rpm 2500 rpm Cooling System Type Liquid-cooled Water-cooled Engine Manufacturer YANMAR Mitsubishi Engine Power (Gross) 24.7 hp 24.7 hp Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader 2,560 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ WarrantyWarranty Length & Coverage Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty ▶ HydraulicsPump Type Gear pump Transmission drive pump Steering Flow 2.77 GPM 2.6 gpm Implement Flow 4.18 GPM 5.9 gpm Total Hydraulic Flow 6.95 gpm 8.5 gpm Hydraulic System Type Live independent Not Published Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 6.95 gpm 8.5 gpm No. of Optional Remote Valves Not Published 1 pair (2 outlets; optional) No. of Standard Remote Valves 1 Not Published ▶ PTO & HitchPTO Rear 540 rpm 540 rpm PTO Type INDEPENDENT Electro-hydraulic rear PTO / mid-PTO Lift Control Type POSITION Position control Hitch Lift Capacity 1,534.4 lb (1,534 lbs.) 1,433 lb Mid-PTO Availability Not Published Standard (2000 rpm) Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity (at 24”) 1,102 lb 1,058 lb ▶ Tire OptionsR3 Turf - Rear 36x13.5-15 320/65-16.5 R3 Turf - Front 25X8.50-14 23X8.50-12 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 12-16.5 | 14-17.5 305/70-16.5 (6PR) R4 Industrial - Front 23X8.50-12; 25X8.50-14 23X8.50-12 (4PR) R1 Agricultural - Rear 9.5-20 255/75-15.3 R1 Agricultural - Front 6.0-12 23X10.50-12 ▶ Fluid CapacityCoolant Capacity 3.6 ℓ (3.8 quart) 1.0 gal Crankcase Capacity 2.7 ℓ (2.9 quart) 1.1 gal Fuel Tank Capacity 25 ℓ (6.6 gallon) 6.6 gal Front Axle Fluid Capacity 4.5 ℓ (4.7 quart) 0.8 gal Transmission / Hydraulic System Capacity 14 ℓ (5.8 gallon) 5.3 gal ▶ Loader & AttachmentsLoader Lift Height 87" 85.7 in Loader Breakout Force 2,059 lbs. 1,687 lb Quick Attach Loader System L85: Skid-steer compatible quick-attach LL2102: Quick-attach front end loader Loader Lift Capacity (Full Height) 1,380 lbs. 1,276 lb ▶ Transmission & DrivetrainClutch Not Applicable Not Applicable No. of Speeds 2 Range (H/L) 2 ranges Transmission Type 2-Range Hydrostatic Transmission Hydrostatic Drive Max Travel Speed (Forward) 13.7 mph (13.7 m/h) Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Differential lock Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsBrakes WET DISC Wet, multi-disc Steering Hydrostatic power steering Hydrostatic power steering Frame Type Rigid frame Not Published Front Axle Type 4WD front axle Front wheel mechanical assist (4WD) Drawbar Capacity Not Published Horizontal load: 3,527 lb; Vertical load: 551 lb pulled / 882 lb pushed Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase Not Published 59 in Overall Width 52.8 in (52.8 inch) 44.9 in Ground Clearance 7.7 in (7.71 inch) Not Published Height to Top of ROPS 89.8 in 84.5 in Height to Top of Cab Model Not Applicable Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes 109.5 in (109.5 inch) Not Published Overall Length with 3-Point Hitch 107.9 in (107.8 inch) 103 in ▶ ITC Company AccessoriesAccessories that fit None tagged yet
