▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 3TNV88C-DKTF D1803-CR-E4-GL2 Engine Type Natural Aspiration Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated No. of Cylinders 3 3 Displacement 100.2 in³ 111.4 in³ Rated Engine Speed 3000 rpm 2600 rpm Engine Power (Gross) 37 hp 37 hp PTO Power Not Published 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Dual Dry Dry paper, dual element Fuel System CRDI Electronic CRS (Common Rail System) Alternator 70 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Dual Gear Pump Tandem pump - gear type Implement Flow 6.3 gpm 8.1 gpm Steering Flow 4.6 gpm 4.7 gpm Total Hydraulic Flow 10.9 gpm 12.8 gpm Overall Hydraulic Pump Flow 6.4 gpm 12.8 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 None standard (up to 3 optional) No. of Optional Remote Valves 1 Optional, up to 3 (double-acting valve or float detent valve options, any position) ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 13.5 gal Coolant Capacity 7.4 qt 7.9 qt Crankcase Capacity 6.0 qt 7.1 qt Transmission / Hydraulic System Capacity 9.25 gal 11.1 gal Front Axle Fluid Capacity 8.7 qt 6.9 qt ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2476 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category I SAE Category 1 Hitch Lift Capacity 2,646 lb 3,750 lb Hitch Lift Capacity (at 24”) 1,764 lb 2646 lb Lift Control Type Position Position control ▶ Transmission & DrivetrainTransmission Type Synchromesh + Constant mesh Hydrostatic No. of Speeds Infinite / 3-Range 3-Range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 21.8 mph 16.5 mph Max Travel Speed (Reverse) Not Published 14.9 mph Clutch Single plate dry clutch (8.86 in diameter); hydraulic clutch assembly for Independent PTO models Not Published Differential Lock & Limited Slip Options 4WD, Differential Lock Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet Disc Wet disc type, mechanically activated Seat Suspension & Adjustability Not Published Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 126 in 115.0 in (without 3-point hitch) Overall Width 53.5 in 59.8 in Wheelbase 66.1 in 71.1 in Ground Clearance 12.8 in 13.5 in Min. Turn Radius without Brakes 116 in 8.9 ft (with brake applied) Height to Top of ROPS 94.4 in 97.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,065 lb 3505 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 8.0-16 7.0-16 R1 Agricultural - Rear 12.4-24 12.4-24 R3 Turf - Front 27x10.5-15 27x10.50-15 R3 Turf - Rear 41x14-20 41x18LL-16.1 R4 Industrial - Front 27x10.5-15 10-16.5 R4 Industrial - Rear 12.5x20 420/70-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA555: Mechanical 2-Lever Quick Coupler (standard); LA805: Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Model L102 LA555 or LA805 Loader Lift Height Not Published LA555: 96.4 in; LA805: 104.7 in Loader Lift Capacity (Full Height) Not Published LA555: 1190 lb; LA805: 1715 lb Loader Breakout Force Not Published LA555: 2030 lb; LA805: 2549 lb (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Engine and power transmission devices: 36 months or 2000 hours; other parts: 24 months or 1500 hours (Tractor Non-Rental & Non-Commercial use) Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit
