▶ EngineEngine Manufacturer Yanmar Mahindra Engine Model 3TNV88-CR CE-38 Engine Type Natural aspiration Naturally aspirated, direct injection, liquid-cooled diesel No. of Cylinders 3 4 Displacement 100.2 in³ 166.7 in³ Rated Engine Speed 3000 rpm 2400 rpm Engine Power (Gross) 36.9 hp 36.9 hp PTO Power 30.2 hp 29.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dual dry Dry dual element Fuel System Common Rail Direct Injection Direct Injection (mCRD fuel-injected) Alternator 55 A, 12 V 90 A, 12 V ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 6.4 gpm 7.6 gpm Steering Flow 4.6 gpm 4.1 gpm Total Hydraulic Flow 11.0 gpm 11.7 gpm Overall Hydraulic Pump Flow 11.0 gpm 11.7 gpm Hydraulic System Type Not Published Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves 1 1 (optional) ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 9 gal Coolant Capacity 7.4 qt 1.85 gal Crankcase Capacity 6.0 qt 2.25 gal Transmission / Hydraulic System Capacity 9.25 gal 8.5 gal Front Axle Fluid Capacity 8.7 qt 2.166 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm @ 2400 rpm Mid-PTO Availability No mid-PTO offered Optional, 2000 rpm @ 2500 engine rpm Category, 3-Point Hitch Category I CAT I Hitch Lift Capacity 2,646 lb 2,646 lb Hitch Lift Capacity (at 24”) 1,764 lb Not Published Lift Control Type Position Position Control ▶ Transmission & DrivetrainTransmission Type 12F/12R Syncro Shuttle HST No. of Speeds 12 forward, 12 reverse Infinite / 3 Ranges Max Travel Speed (Forward) 15.0 mph 15.05 mph Max Travel Speed (Reverse) Not Published 14.38 mph Clutch Single plate dry clutch (8.86 in diameter); hydraulic clutch assembly for Independent PTO models Damper Differential Lock & Limited Slip Options 4WD, differential lock Bevel gears with diff-lock ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Not Published Steering Hydrostatic power steering Power steering Brakes Wet disc Wet Disc Brake, Mechanical Seat Suspension & Adjustability Suspension seat with armrests and retractable seat belt, standard Seat with mechanical suspension, adjustable headrest, folding armrests Front Axle Type Center-pivot, reverse Elliot type (4WD) Center pin Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 53.5 in 63.2 in Wheelbase 64.5 in 67.7 in Ground Clearance 12.8 in 14.5 in Min. Turn Radius without Brakes 116 in Not Published Height to Top of ROPS 94.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94.4 in Overall Length 126 in (with 3-point hitch) 119.3 in ▶ WeightTractor Weight (Base) 3,020 lb 3,351 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 4,336 lb (3,351 + 985, computed; 2638CL loader shipping weight) ▶ Tire OptionsTire Size & Options Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt), R14 (Opt) R1 Agricultural, R4 Industrial R1 Agricultural - Front 7-16 7-16 6PR R1 Agricultural - Rear 11.2x24 11.2-24 4PR R3 Turf - Front 28x8.5-15 Not Published R3 Turf - Rear 41x14-20 Not Published R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 43x16-20 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System L102: Skid-steer compatible quick-attach 2638CL: quick-attach adapter included Loader Model L102 2638CL (66 in bucket) Loader Lift Height L102: 102 in 2638CL: 101.4 in Loader Lift Capacity (Full Height) L102: 2,116 lb to full height 2638CL: 1,634 lb (at pivot pin) Loader Breakout Force L102: 3,435 lb 2638CL: 2,696 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 8 years or 3,000 hours, no deductible, parts and labor Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
