▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88-CR 3TNV88-CR Engine Type Natural aspiration Natural aspiration No. of Cylinders 3 3 Displacement 100.2 in³ 100.2 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 36.9 hp 36.9 hp PTO Power 30.2 hp 30.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual dry Dual dry Fuel System Common Rail Direct Injection Common Rail Direct Injection Alternator 70 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Dual gear pump Dual gear pump Implement Flow 6.4 gpm 6.4 gpm Steering Flow 4.6 gpm 4.6 gpm Total Hydraulic Flow 11.0 gpm 11.0 gpm Overall Hydraulic Pump Flow 11.0 gpm 11.0 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 9.0 gal Coolant Capacity 7.4 qt 7.4 qt Crankcase Capacity 6.0 qt 6.0 qt Transmission / Hydraulic System Capacity 9.25 gal 9.25 gal Front Axle Fluid Capacity 8.7 qt 8.7 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered No mid-PTO offered Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,646 lb 2,646 lb Hitch Lift Capacity (at 24”) 1,764 lb 1,764 lb Lift Control Type Position Position ▶ Transmission & DrivetrainTransmission Type 12F/12R Syncro Shuttle 12F/12R Syncro Shuttle No. of Speeds 12 forward, 12 reverse 12 forward, 12 reverse Max Travel Speed (Forward) 15.0 mph 15.0 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Single plate dry clutch (8.86 in diameter); hydraulic clutch assembly for Independent PTO models Single plate dry clutch (8.86 in diameter); hydraulic clutch assembly for Independent PTO models Differential Lock & Limited Slip Options 4WD, differential lock 4WD, differential lock ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Suspension seat with armrests and retractable seat belt, standard Suspension seat with armrests and retractable seat belt, standard Front Axle Type Center-pivot, reverse Elliot type (4WD) Center-pivot, reverse Elliot type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 58.0 in 53.5 in Wheelbase 64.5 in 64.5 in Ground Clearance 12.8 in 12.8 in Min. Turn Radius without Brakes 116 in 116 in Height to Top of ROPS Not Published 94.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.5 in Not Published Overall Length 128 in (with 3-point hitch) 126 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,417 lb 3,020 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt), R14 (Opt) Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt), R14 (Opt) R1 Agricultural - Front 7-16 7-16 R1 Agricultural - Rear 11.2x24 11.2x24 R3 Turf - Front 28x8.5-15 28x8.5-15 R3 Turf - Rear 41x14-20 41x14-20 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 43x16-20 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System L102: Skid-steer compatible quick-attach L102: Skid-steer compatible quick-attach Loader Model L102 L102 Loader Lift Height L102: 102 in L102: 102 in Loader Lift Capacity (Full Height) L102: 2,116 lb to full height L102: 2,116 lb to full height Loader Breakout Force L102: 3,435 lb L102: 3,435 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 8 years or 3,000 hours, no deductible, parts and labor Basic 2 years or 2,000 hours; powertrain 8 years or 3,000 hours, no deductible, parts and labor ▶ ITC Company AccessoriesAccessories that fit
