▶ EngineEngine Manufacturer Yanmar KIOTI (Daedong) Engine Model 4TNV86T-CR 3F183T Engine Type 4-cycle, inline, water-cooled, turbocharged diesel KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI No. of Cylinders 4 3 Displacement 127.6 in³ 111.4 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 55.1 hp 55 hp PTO Power RK55S: 44.9 hp; RK55H: 42.2 hp; RK55SC: 44.9 hp; RK55HC: 42.2 hp 46 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled, forced circulation with fan Water-cooled Air Cleaner Dry dual element Dry type element Fuel System Common Rail Direct Injection Common Rail Direct Injection (CRDI) Alternator 70 A, 12 V Not Published ▶ HydraulicsPump Type Dual Gear Pump Gear Implement Flow 9.5 gpm 8.2 gpm Steering Flow 5.0 gpm 8.2 gpm Total Hydraulic Flow 14.5 gpm 16.5 gpm Overall Hydraulic Pump Flow 9.5 gpm 16.5 gpm Hydraulic System Type Independent fully live hydraulic pump with separate reservoir; position control with isolating and response control Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 15.85 gal 14.8 gal Coolant Capacity 2.5 gal 2.0 gal Crankcase Capacity 5.6 qt 1.58 gal Transmission / Hydraulic System Capacity 9.24 gal 14.53 gal Front Axle Fluid Capacity 2.64 gal 1.8 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability RK55S, RK55SC: no mid-PTO offered Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I & II Hitch Lift Capacity 3,314 lb 3,538 lb Hitch Lift Capacity (at 24”) 2,945 lb 3,177 lb Lift Control Type Position and draft control Position with Draft Control ▶ Transmission & DrivetrainTransmission Type RK55S, RK55SC: 16F/16R Syncro Shuttle w/creeper; RK55H, RK55HC: Hydrostatic, 3-range Synchro Shuttle No. of Speeds RK55S, RK55SC: 16 forward, 16 reverse; RK55H, RK55HC: infinite (3 ranges) 24x24 Max Travel Speed (Forward) RK55S, RK55SC: 18.4 mph; RK55HC: 17.9 mph 17.35 mph Max Travel Speed (Reverse) RK55S, RK55SC: 16.1 mph 15.42 mph Clutch RK55S, RK55SC: main dry single disc, mechanical (10.24 in diameter); PTO multiple wet disc Dry Type Single Stage Differential Lock & Limited Slip Options 4WD (MFWD) standard; bevel-gear rear differential lock Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Transmission case, clutch housing, engine and front axle support bolted together to form a rigid unit Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Wet disc, mechanical, foot operated Wet Multi Disc Seat Suspension & Adjustability Suspension seat with armrests and retractable seat belt, standard Adjustable Seat Front Axle Type Center-pivot, reverse Elliot type (4WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 141.3 in 139.6 in Overall Width 63.8 in 65.7 in Wheelbase 76.2 in 75.6 in Ground Clearance 13.8 in 15.7 in Min. Turn Radius without Brakes Not Published 10.0 ft Height to Top of ROPS RK55S, RK55H: 102.1 in 103.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model RK55SC, RK55HC: 99.6 in Not Published ▶ WeightTractor Weight (Base) RK55S, RK55H: 3,814 lb; RK55SC, RK55HC: 4,233 lb 4,209 lb Weight with ROPS and Loader 5,075 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5x16 9.5-16 R1 Agricultural - Rear 14.9x24 16.9-24 R3 Turf - Front 12x16.5 29-12.5-15 R3 Turf - Rear 16.9x24 21.5L-16.1 R4 Industrial - Front 12x16.5 10-16.5 R4 Industrial - Rear 16.9x24 17.5-24 ▶ Loader & AttachmentsQuick Attach Loader System L110: Skid-steer compatible quick-attach Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model L110 KL6010 Loader Lift Height L110: 110 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) L110: 2,478 lb at pivot pin to full height KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force L110: 4,938 lb at pivot pin KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 2-year full machine warranty; 8-year, 3,000-hour powertrain warranty (no deductible, parts and labor) Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor ▶ ITC Company AccessoriesAccessories that fit
